Chevrolet Traverse I facelift (2012-2017) Courtesy lamps circuit

BLK WIRE BLK/WHT WIRE BODY CONTROL MODULE (BCM) (UNDER LEFT SIDE OF DASH) COMPUTER DATA LINES SYSTEM COURTESY LAMP HIGH CTRL COURTESY LAMPS ON COURTESY LAMPS ON SWITCH COURTESY LAMPS VOLT CTSY FUSE DK GRN WIRE DOME OVERRIDE SWITCH DRIVER DOOR LATCH ASSEMBLY DRIVER DOOR SWITCH PANEL CONTROL MODULE GRY WIRE GRY/BLK WIRE HEADLAMP SWITCH HOT AT ALL TIMES I/P FUSE BLOCK INADV/ PWR/LED FUSE INTERIOR LAMP SW SIG LEFT I/P COURTESY LAMP LEFT LIFTGATE COURTESY LAMP LEFT REAR DOOR LATCH ASSEMBLY (REAR OF LEFT REAR DOOR) LF DOOR AJAR SW SIG LIFTGATE AJAR LIFTGATE LATCH ASSEMBLY (W/ MANUAL LIFTGATE) (BOTTOM CENTER OF LIFTGATE) LOGIC LOW REF LOW SPEED GMLAN LR DOOR AJAR SW SIG LT BLU/BLK WIRE LT GRN/BLK WIRE ORG/ WIRE PASSENGER DOOR LATCH ASSEMBLY PASSENGER DOOR SWITCH PANEL CONTROL MODULE PNK/BLK WIRE PPL RED/WHT WIRE RF DOOR AJAR SW SIG RIGHT I/P COURTESY LAMP RIGHT LIFTGATE COURTESY LAMP RIGHT REAR DOOR LATCH ASSEMBLY (REAR RIGHT REAR DOOR) RR DOOR AJAR SW SIG SER DATA SW SIG TAN/WHT WIRE W/ DOOR SILL PLATE W/O DOOR SILL PLATE W/ EXPRESS UP/DOWN WINDOWS W/O EXPRESS UP/DOWN WINDOWS YEL WIRE

BLK WIRE DRIVER DOOR SILL PLATE LAMP FRONT OVERHEAD CONSOLE DOME/ READING LAMPS GRY/BLK WIRE LEFT SUNSHADE NCA WIRE ORG/ WIRE PASSENGER DOOR SILL PLATE LAMP RIGHT SUNSHADE W/ SUNROOF, REAR SEAT ENTERTAINMENT W/O REAR SEAT ENTERTAINMENT
