Chevrolet Traverse I facelift (2012-2017) video display fuse holder Wiring diagram
This page shows the only wiring diagram for the component.video display fuse holder, which is found in the car Chevrolet Traverse I facelift (2012-2017). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram video display fuse holder (1 of 1)
ACC VOLT
ANTENNA
BLK WIRE
BODY CONTROL MODULE (BCM)
CLK+
DRIVER SEAT HEADREST VIDEO DISPLAY
DVD CONTROL MODULE
DVD RELAY
FM ANT
HOT AT ALL TIMES
I/P FUSE BLOCK
IGN VOLT
INFOTMNT FUSE
L AUDIO (+)
PASSENGER SEAT HEADREST VIDEO DISPLAY
PNK/BLK WIRE
POWER DISTRIBUTION SYSTEM
R AUDIO (+)
RED WIRE
SERIAL DATA
VIDEO DISPLAY FUSE HOLDER
VIDEO SIG
WHT WIRE
YEL WIRE
Go to component -> Video system circuit, w/ spo accessory -> VIDEO DISPLAY FUSE HOLDER
