Chevrolet Traverse I facelift (2012-2017) trans case actuator low ctrl Wiring diagram
This page shows the only wiring diagram for the component.trans case actuator low ctrl, which is found in the car Chevrolet Traverse I facelift (2012-2017). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram trans case actuator low ctrl (1 of 1)
AWD FUSE
BATT POS VOLT
BLK WIRE
COMMUNICATION ENABLE
COMPUTER DATA LINES SYSTEM
DK GRN WIRE
DRIVER INFORMATION CENTER (DIC) DISPLAY
GROUND
HI SPD GMLAN SER DATA BUS-
HOT AT ALL TIMES
INSTRUMENT CLUSTER
LOGIC
LOW GMLAN SERIAL DATA
LOW REFERENCE
LT BLU WIRE
REAR DIFFERENTIAL CLUTCH CONTROL MODULE
REAR DIFFERENTIAL CLUTCH SOLENOID VALVE
RED/WHT WIRE
TAN WIRE
TAN/BLK WIRE
TRANS CASE ACTUATOR HI CTRL
TRANS CASE ACTUATOR LOW CTRL
TRANS CASE FLUID TEMP SIG
UNDERHOOD FUSE BLOCK
Go to component -> Rear differential lock circuit -> TRANS CASE ACTUATOR LOW CTRL
