Chevrolet Traverse I facelift (2012-2017) pwr mode Wiring diagram
This page shows the only wiring diagram for the component.pwr mode, which is found in the car Chevrolet Traverse I facelift (2012-2017). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pwr mode (1 of 1)
BCM FUSE
BLK WIRE
BODY CONTROL MODULE (BCM)
CAMERA SHIELD
CAMERA SIG 2
DK BLU WIRE
GRY WIRE
HOT AT ALL TIMES
I/P FUSE BLOCK
IGN VOLT
INSIDE REARVIEW MIRROR (ISRVM)
INSTRUMENT CLUSTER SYSTEM
LOGIC
LOW REF
LT BLU WIRE
MIRROR DISPLAY
MIRRORS SYSTEM
NCA WIRE
ORG/ WIRE
PNK WIRE
PNK/BLK WIRE
PWR MODE
RADIO
REARVIEW CAMERA
RED WIRE
RED/WHT WIRE
REV
SIG
TAN WIRE
W/O INSIDE REAR VIEW MIRROR
WHT WIRE
YEL WIRE
Go to component -> Rear view camera circuit -> PWR MODE
