Chevrolet Traverse I facelift (2012-2017) mirror sig camera sig + Wiring diagram
This page shows the only wiring diagram for the component.mirror sig camera sig +, which is found in the car Chevrolet Traverse I facelift (2012-2017). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram mirror sig camera sig + (1 of 1)
BACK-UP
BCK/UP/ STOP FUSE
BLK WIRE
BLK/DK GRN WIRE
BLK/GRY WIRE
BLK/LT GRN WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BODY CONTROL MODULE (BCM)
BRN/WHT WIRE
CALL
CAMERA SIG (-)
DK BLU WIRE
DK GRN/WHT WIRE
DRIVER OUTSIDE REARVIEW MIRROR
EMERGENCY
GREEN
GRY WIRE
HOT AT ALL TIMES
I/P FUSE BLOCK
IGN
INSIDE REARVIEW MIRROR (ISRVM)
KEYPAD GREEN LED
KEYPAD RED LED WIRE
KEYPAD SIG
LCD SIG
LED SIG
LOGIC
LOW REF
LT BLU WIRE
LT GRN/BLK WIRE
MAX
MIRROR DIMMING
MIRROR DISPLAY
MIRROR SIG CAMERA SIG +
NAVIGATION SYSTEM
OFF MIN
ONSTAR
PNK WIRE
POWER DISTRIBUTION SYSTEM
RED WIRE
RED/WHT WIRE
SUPPLY VOLTAGE
TELEMATICS BUTTON ASSEMBLY
TELEMATICS COMMUNICATIONS INTERFACE MODULE (VCIM)
W/ ONSTAR
W/ REAR VIEW CAMERA
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Electrochromic mirror circuit -> MIRROR SIG CAMERA SIG +
