Passenger power seat circuit for Chevrolet Traverse I (2008-2012)
Passenger power seat circuit
BLK WIRE
DK BLU WIRE
DK GRN WIRE
HOT AT ALL TIMES
I/P FUSE BLOCK (BEHIND RIGHT END OF DASH)
LT GRN WIRE
PASSENGER SEAT ADJUSTER SWITCH
PASSENGER SEAT HORIZONTAL MOTOR (UNDER FRONT PASSENGER'S SEAT)
PASSENGER SEAT RECLINE MOTOR (IN FRONT PASSENGER'S SEAT BACK)
RED WIRE
RED/WHT WIRE
RT/PWR/SEAT CIRCUIT BREAKER
RWD
TAN WIRE
W/ 4-WAY PASSENGER SEAT ADJUSTER
W/ MULTI- DIRECTIONAL PASSENGER SEAT ADJUSTER
WHT WIRE
