Chevrolet Traverse I (2008-2012) Cooling fan circuit

45 46 42 55 HI SPD CLG FAN LO SPD CLG FAN SER DATA BUS + SER DATA BUS - 82 44 ECT LOW REF BLK WIRE COMPUTER DATA LINES SYSTEM COOLING FAN SPEED CONTROL RELAY DK BLU WIRE DK GRN WIRE DRIVER INFORMATION CENTER (DIC) DISPLAY EMISSION 2 FUSE ENGINE CONTROL MODULE (ECM) (LEFT SIDE OF ENGINE) ENGINE COOLANT TEMPERATURE (ECT) SENSOR (LEFT SIDE OF ENGINE) FAN 1 FUSE FAN-2 FUSE GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ POWERTRAIN RELAY ENERGIZED INSTRUMENT PANEL CLUSTER (IPC) LEFT COOLING FAN (MOUNTED TO REAR LEFT SIDE OF RADIATOR) LEFT HIGH SPEED COOLING FAN RELAY LOGIC LT BLU WIRE LT GRN WIRE RED WIRE RIGHT COOLING FAN (MOUNTED TO REAR RIGHT SIDE OF RADIATOR) RIGHT HIGH SPEED COOLING FAN RELAY TAN WIRE TAN/BLK WIRE UNDERHOOD FUSE BLOCK WHT WIRE YEL WIRE
