Compressor circuit, auto a/c for Chevrolet Traverse I (2008-2012)
Compressor circuit, auto a/c
44 55 42 11 35 39 A/C CLUTCH HI SPD BUS - HI SPD BUS + LOW REF
A/C COMPRESSOR CLUTCH (LOWER LEFT FRONT OF ENGINE)
A/C COMPRESSOR CLUTCH RELAY
A/C PRESSURE
A/C REFRIGERANT PRESSURE SENSOR (NEAR REAR OF A/C COMPRESSOR)
AC CLTCH FUSE
BLK/WHT WIRE
COMPUTER DATA LINES SYSTEM
DK GRN WIRE
DK GRN/WHT WIRE
DRIVER INFORMATION CENTER (DIC) DISPLAY
EMISSION 2 FUSE
ENGINE CONTROL MODULE (ECM) (LEFT SIDE OF ENGINE)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ POWERTRAIN RELAY ENERGIZED
LOGIC HVAC CONTROL MODULE
LOGIC INSTRUMENT PANEL CLUSTER (IPC)
ORG/BLK WIRE
TAN WIRE
TAN/BLK WIRE
UNDERHOOD FUSE BLOCK (ABOVE RIGHT FRONT WHEELWELL)
WHT WIRE
