Chevrolet Traverse I (2008-2012) w/ power folding wiring diagram
This page shows the only wiring diagram for the component.w/ power folding, which is found in the car Chevrolet Traverse I (2008-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
w/ power folding wiring diagram (1 of 1)
BLK WIRE
DATA LINK CONNECTOR (DLC)
DIGITAL HAZARD DIGITAL VIDEO SWITCH VIDEO DISC (DVD) CONTROL DISC MODULE RELAY
DK BLU WIRE
DOOR LOCK RELAY
DRIVER DOOR DOOR UNLATCH UNLOCK RELAY RELAY
DRIVER DOOR LATCH
DRIVER DOOR LOCK SWITCH
DRIVER DOOR LOCK/ WINDOW SWITCH
DRIVER OUTSIDE REARVIEW MIRROR
DRIVER SEAT ADJUSTER SWITCH
DRIVER SEAT LUMBAR SWITCH
DRIVER WINDOW MOTOR
DRIVER WINDOW SWITCH
I/P I/P MULTI- ACCESSORY FUNCTION POWER SWITCH OUTLET
LEFT REAR DOOR LATCH
LEFT REAR WINDOW SWITCH
NCA WIRE
PASSENGER DOOR LATCH
PASSENGER DOOR LOCK SWITCH
PASSENGER DOOR LOCK/ WINDOW SWITCH
PASSENGER OUTSIDE REARVIEW MIRROR
PASSENGER WINDOW SWITCH
REAR WINDOW WASHER PUMP RELAY
RIGHT RIGHT REAR REAR WINDOW DOOR SWITCH LATCH
W/ 4-WAY POWER PASSENGER SEAT ADJUSTER, W/ FRONT SEAT HEATER
W/ EXPRESS POWER WINDOWS
W/ FRONT HEATED SEAT
W/ MANUAL FOLDING
W/ MULTI-DIRECTIONAL POWER PASSENGER SEAT ADJUSTER
W/ POWER FOLDING
W/ SPO DVD
W/ TRAILER PROVISIONS
W/ W/ POWER MANUAL FOLDING FOLDING
W/ W/O EXPRESS EXPRESS POWER POWER WINDOWS WINDOWS
W/O EXPRESS POWER WINDOWS
W/O FRONT HEATED SEAT
W/O MEMORY, 8-WAY DRIVER POWER SEAT
Go to component -> Ground distribution circuit (3 of 5) -> W/ POWER FOLDING
