Chevrolet Traverse I (2008-2012) rear defog ind Wiring diagram
This page shows the only wiring diagram for the component.rear defog ind, which is found in the car Chevrolet Traverse I (2008-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear defog ind (1 of 1)
3 7 LOW REF HEATING ELEMENT VOLT
AUTOMATIC A/C MANUAL A/C
BLK WIRE
BLK/WHT WIRE
COMPUTER DATA LINES SYSTEM
COMPUTER DATA LINES SYSTEM 628 2267
DK GRN WIRE
DRIVER OUTSIDE REARVIEW MIRROR (ON DRIVER'S DOOR)
DRIVER OUTSIDE REARVIEW MIRROR (W/O MEMORY) (ON DRIVER'S DOOR)
HOT AT ALL TIMES
HTD MIR FUSE
HVAC CONTROL MODULE
LOGIC
LOGIC DRIVER DOOR LOCK/WINDOW SWITCH (W/ MEMORY)
LOGIC PASSENGER DOOR LOCK/WINDOW SWITCH (W/ MEMORY)
LOW SPEED GMLAN SER DATA
LT GRN WIRE
NCA WIRE
ORG/ WIRE
PASSENGER OUTSIDE REARVIEW MIRROR (ON FRONT PASSENGER'S DOOR)
PASSENGER OUTSIDE REARVIEW MIRROR (W/O MEMORY)
PPL
REAR DEFOG IND
REAR DEFOG REAR DEFOG SWITCH SER DATA
REAR WINDOW DEFOG RELAY
REAR WINDOW DEFOGGER GRID
RR DEFOG FUSE
UNDERHOOD FUSE BLOCK (ABOVE RIGHT FRONT WHEELWELL)
WHT WIRE
Go to component -> Defoggers circuit -> REAR DEFOG IND
