Chevrolet Traverse I (2008-2012) inflatable restraint i/p module indicator clock Wiring diagram
This page shows the only wiring diagram for the component.inflatable restraint i/p module indicator clock, which is found in the car Chevrolet Traverse I (2008-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram inflatable restraint i/p module indicator clock (1 of 1)
AUXILIARY BLOWER MOTOR CONTROL MODULE
BLK WIRE
BRAKE HVAC FLUID CONTROL LEVEL MODULE SWITCH
CHEVROLET, W/ KEYLESS ENTRY
COURTESY/ READING LAMPS
DATA LINK CONNECTOR (DLC)
ELECTRONIC COMPASS MODULE
FRONT OVERHEAD CONSOLE COURTESY/ READING LAMPS
GMC
HARNESS)
HEADLAMP SWITCH
HORN SWITCH
IGNITION LOCK CYLINDER CONTROL ACTUATOR
INFLATABLE RESTRAINT FRONT PASSENGER PRESENCE SYSTEM (PPS) MODULE
INFLATABLE RESTRAINT I/P MODULE INDICATOR CLOCK
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (SDM)
INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL
LEFT STEERING WHEEL CONTROL BODY CONTROL SWITCH MODULE (BCM)
LEFT SUNSHADE
MANUAL A/C AUTOMATIC A/C
OVERHEAD CONSOLE ACCENT LAMP
PROV- ISIONS
REAR SEAT AUDIO (RSA) CONTROL
REMOTE CONTROL DOOR LOCK RECEIVER (RCDLR)
RIGHT REAR SIDE MARKER LAMP
RIGHT SUNSHADE
RIGHT TAIL LAMP
RIGHT TAIL/ STOP/ TURN SIGNAL LAMP
SUNROOF CONTROL MODULE
SUNROOF SHADE MODULE
THEFT DETERRENT MODULE (TDM)
TRAILER CONNECTOR
TURN SIGNAL/ MULTI-FUNCTION SWITCH
W/ REAR AUDIO CONTROL
W/ SUNROOF
W/ SUNROOF, REAR SEAT ENTERTAINMENT
W/ SUNROOF, W/O REAR SEAT ENTERTAINMENT
W/ TRAILER
WHT WIRE
Go to component -> Ground distribution circuit (4 of 5) -> INFLATABLE RESTRAINT I/P MODULE INDICATOR CLOCK
