Chevrolet Traverse I (2008-2012) driver i/p multi-function window switch switch Wiring diagram
This page shows the only wiring diagram for the component.driver i/p multi-function window switch switch, which is found in the car Chevrolet Traverse I (2008-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver i/p multi-function window switch switch (1 of 1)
AUTOMATIC TRANSMISSION SHIFT LEVER POSITION INDICATOR
AUXILIARY HVAC CONTROL ASSEMBLY
AUXILIARY RADIO/ HVAC CONTROL (IF EQUIPPED)
BLK WIRE
DK BLU WIRE
DRIVER DOOR LOCK SWITCH
DRIVER HEATED SEAT SWITCH (W/ FRONT HEATER SEAT)
DRIVER HEATED, COOLED SEAT SWITCH (W/ FRONT COOLING HEATER SEAT)
DRIVER I/P MULTI-FUNCTION WINDOW SWITCH SWITCH
GARAGE DOOR OPENER (GDO)
GRY WIRE
LEFT REAR WINDOW SWITCH
LOGIC
NCA WIRE
OUTSIDE REARVIEW MIRROR SWITCH
PASSENGER DOOR LOCK SWITCH
PASSENGER HEATED SEAT SWITCH (W/ FRONT HEATER SEAT)
PASSENGER HEATED, COOLED SEAT SWITCH (W/ FRONT COOLING HEATER SEAT)
PASSENGER WINDOW SWITCH
PPL/WHT WIRE
REAR SEAT AUDIO (RSA) OVERHEAD CONTROL CONSOLE ACCENT LAMP
RIGHT REAR WINDOW SWITCH
SUNROOF SHADE SWITCH
SUNROOF SWITCH
W/ EXPRESS UP/DOWN WINDOWS
W/ FRONT HEATED SEATS, REAR SEAT RADIO CONTROLS
W/ REAR AUDIO CONTROL
W/ REAR SEAT RADIO CONTROL, EARPHONE JACKS
W/ UNIVERSAL GARAGE DOOR OPENER, SUNROOF
W/ UNIVERSAL GARAGE DOOR OPENER, W/O SUNROOF
W/O EXPRESS UP/DOWN WINDOWS
W/O FRONT HEATED SEATS, REAR SEAT RADIO CONTROLS
W/O REAR SEAT RADIO CONTROL, EARPHONE JACKS
Go to component -> Instrument illumination circuit (2 of 2) -> DRIVER I/P MULTI-FUNCTION WINDOW SWITCH SWITCH
