Chevrolet Traverse I (2008-2012) automatic transmission shift lever ignition lock cylinder control switch wiring diagram
This page shows the only wiring diagram for the component.automatic transmission shift lever ignition lock cylinder control switch, which is found in the car Chevrolet Traverse I (2008-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
automatic transmission shift lever ignition lock cylinder control switch wiring diagram (1 of 1)
AUTOMATIC TRANSMISSION SHIFT LEVER IGNITION LOCK CYLINDER CONTROL SWITCH
BLK WIRE
BODY CONTROL MODULE (BCM) (UNDER LEFT SIDE OF DASH)
HOT AT ALL TIMES
IGN VOLT
IGNITION LOCK CYLINDER CONTROL ACTUATOR
POWER DISTRIBUTION SYSTEM
PPL
RED/WHT WIRE
RVC SNSR FUSE
UNDERHOOD FUSE BLOCK (ABOVE RIGHT FRONT WHEELWELL)
W/ SPO DVD
WHT WIRE
YEL WIRE
Go to component -> Ignition lock solenoid circuit -> AUTOMATIC TRANSMISSION SHIFT LEVER IGNITION LOCK CYLINDER CONTROL SWITCH
