Chevrolet Traverse I (2008-2012) 9 10 8 current sens sig low ref sply volt Wiring diagram
This page shows the only wiring diagram for the component.9 10 8 current sens sig low ref sply volt, which is found in the car Chevrolet Traverse I (2008-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 9 10 8 current sens sig low ref sply volt (1 of 1)
10 30 225 23 GENERATOR TURN ON GENERATOR FIELD
10 9 B+ GND
42 55 2500 2501 HI SPD GMLAN HI SPD GMLAN
9 10 8 CURRENT SENS SIG LOW REF SPLY VOLT
AIR BAG FUSE
BATTERY
BATTERY CURRENT SENSOR (BEHIND FRONT PASSENGER'S SEAT)
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (BCM) (UNDER LEFT SIDE OF DASH)
BOOST GAUGE
BRN WIRE
CHARGE IND
COMPUTER DATA LINES SYSTEM
DK GRN WIRE
DRIVER INFORMATION CENTER (DIC)
ENGINE CONTROL MODULE (ECM) (LEFT SIDE OF ENGINE)
GENERATOR
GENERATOR INLINE FUSE
GRY WIRE
HI SPD GMLAN HI SPD GMLAN
HOT W/ IGNITION MAIN RELAY ENERGIZED
I/P FUSE BLOCK (BEHIND RIGHT END OF DASH)
INSTRUMENT PANEL CLUSTER (IPC)
LOGIC
ORG/ WIRE
PNK SPLY VOLT LOW REF CURRENT SENS SIG WIRE
PNK WIRE
POWER DISTRIBUTION SYSTEM
RED WIRE
RED/WHT WIRE
RVC SNSR FUSE
STARTER MOTOR
TAN WIRE
TAN/BLK WIRE
UNDERHOOD FUSE BLOCK (ABOVE RIGHT FRONT WHEELWELL)
VOLT
WHT WIRE
Go to component -> Charging circuit -> 9 10 8 CURRENT SENS SIG LOW REF SPLY VOLT
