Chevrolet Traverse I (2008-2012) 5 9 12 serial ambient low ref Wiring diagram

19 14 LOW REF EVAP A/C ON IND 44 55 42 11 35 39 A/C CLUTCH HI SPD BUS - HI SPD BUS + LOW REF 5 9 12 SERIAL AMBIENT LOW REF 5060 735 61 COMPUTER DATA LINES SYSTEM 20 25 A/C COMPRESSOR CLUTCH (LOWER LEFT FRONT OF ENGINE) A/C COMPRESSOR CLUTCH RELAY A/C ON SW A/C PRESSURE A/C REFRIGERANT PRESSURE SENSOR (NEAR REAR OF A/C COMPRESSOR) AC CLTCH FUSE BLK WIRE BLK/WHT WIRE COMPUTER DATA LINES SYSTEM DK GRN WIRE DK GRN/WHT WIRE DRIVER INFORMATION CENTER (DIC) DISPLAY EMISSION 2 FUSE ENGINE CONTROL MODULE (ECM) (LEFT SIDE OF ENGINE) EVAPORATOR TEMPERATURE SENSOR (RIGHT SIDE OF HVAC MODULE) GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ POWERTRAIN RELAY ENERGIZED HVAC CONTROL MODULE LOGIC LOGIC INSTRUMENT PANEL CLUSTER (IPC) LT GRN/BLK WIRE ORG/BLK WIRE TAN WIRE TAN/BLK WIRE UNDERHOOD FUSE BLOCK (ABOVE RIGHT FRONT WHEELWELL) WHT WIRE YEL WIRE
