Chevrolet Traverse I (2008-2012) 4 6 lf turn sig ind lamp volt stop lamp sply voltage Wiring diagram

1 3 4 5 B+ B+ B+ RIGHT TURN SIG IND LAMP 15 14 13 10 5 VOLT LOW REFERENCE STOP LAMP SW SIG LOW SPD GMLAN SERIAL DATA 15 16 19 LEFT TURN SIGNAL RIGHT TURN SIGNAL HAZARD SW SIG 24 8 20 PARK LAMP RELAY CTRL REAR PARK LAMPS VOLTAGE RH TAIL LMP DETECTION SIG 4 6 LF TURN SIG IND LAMP VOLT STOP LAMP SPLY VOLTAGE AUTO BCK/UP/STOP FUSE BLK WIRE BLK/WHT WIRE BLUNT CUT TRAILER PROVISION (IF EQUIPPED) BODY CONTROL MODULE (BCM) (UNDER LEFT SIDE OF DASH) BRAKE PEDAL POSITION SENSOR (TOP OF BRAKE PEDAL ASSEMBLY) BRN/WHT WIRE CENTER HIGH MOUNTED STOP LAMP (CHMSL) CHEVROLET CHEVROLET/ GMC COMPUTER DATA LINES SYSTEM COMPUTER DATA LINES SYSTEM 1080 301 5357 DK BLU/WHT WIRE DK GRN WIRE DRIVER OUTSIDE REARVIEW MIRROR (ON DRIVER'S DOOR) ENGINE CONTROL MODULE (ECM) (LEFT SIDE OF ENGINE) GMC GMC/ CHEVROLET GRY WIRE HAZARD SWITCH HEAD HEADLAMP SWITCH HIGH SPEED GMLAN SERIAL DATA BUS + HOT AT ALL TIMES I/P FUSE BLOCK (BEHIND RIGHT END OF DASH) LT/TRN/SIG FUSE LAMP LEFT REAR SIDE MARKER LEFT REAR SIDE MARKER LAMP LEFT STOP, TURN SIGNAL LAMP LEFT TAIL LAMP LEFT TAIL LAMP ASSEMBLY LEFT TAIL/ STOP, TURN LOGIC LT BLU WIRE LT BLU/WHT WIRE LT GRN WIRE OFF PARK PASSENGER OUTSIDE REARVIEW MIRROR (ON FRONT PASSENGER'S DOOR) PPL RED WIRE RED/WHT WIRE RIGHT REAR SIDE MARKER LAMP RIGHT REAR SIDE MARKER LAMP RIGHT TAIL/ STOP, TURN SIGNAL LAMP RIGHT STOP, RIGHT TURN TAIL SIGNAL LAMP LAMP RIGHT TAIL LAMP ASSEMBLY RT/TRN/SIG FUSE SIGNAL LAMP STP LP SW SIG TAN WIRE TAN/BLK WIRE TURN SIGNAL/ MULTI-FUNCTION SWITCH UNDERHOOD FUSE LOCK (ABOVE RIGHT FRONT WHEELWELL) W/ FOLDING MIRRORS W/ POWER FOLDING W/ MANUAL FOLDING WHT WIRE YEL WIRE YEL/BLK WIRE
