Chevrolet Traverse I (2008-2012) 3 21 inst panel lamp volt led dimming signal Wiring diagram
This page shows the only wiring diagram for the component.3 21 inst panel lamp volt led dimming signal, which is found in the car Chevrolet Traverse I (2008-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 3 21 inst panel lamp volt led dimming signal (1 of 1)
13 4 MEMORY SW DIMMING LOW REF
2 18 12 11 B+ LED DIMMING SIGNAL
3 2 12 17 INST PANEL LAMP VOLT B+ HEADLAMPS ON HEADLAMPS OFF
3 21 INST PANEL LAMP VOLT LED DIMMING SIGNAL
BCM FUSE
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (BCM) (UNDER LEFT SIDE OF DASH)
BRN/WHT WIRE
CLOCK
COMPUTER DATA LINES SYSTEM
DIMMING SWITCH SIGNAL
DK BLU/WHT WIRE
DK GRN WIRE
DRIVER INFORMATION CENTER (DIC) SWITCH (IF EQUIPPED)
DRIVER MEMORY SEAT ADJUSTER SWITCH
GRY WIRE
HAZARD SWITCH
HEAD
HEAD UP DISPLAY (HUD) SWITCH (IF EQUIPPED)
HEADLAMP SWITCH
HOT AT ALL TIMES
HVAC CONTROL MODULE (W/ FRONT A/C)
I/P FUSE BLOCK (BEHIND RIGHT END OF DASH)
INAD/PWR/ LED FUSE
LEFT STEERING WHEEL CONTROL SWITCH
LOGIC DRIVER DOOR LOCK/ WINDOW SWITCH
LOW SPEED GMLAN
NCA WIRE
OFF
ORG/WHT WIRE
PARK AUTO
PPL/WHT WIRE
RADIO
RED/WHT WIRE
RIGHT STEERING WHEEL CONTROL SWITCH
STR/ WHL/ILLUM FUSE
W/ ACCESSORY STEERING WHEEL CONTROL
W/O ACCESSORY STEERING WHEEL CONTROL
WHT WIRE
Go to component -> Instrument illumination circuit (1 of 2) -> 3 21 INST PANEL LAMP VOLT LED DIMMING SIGNAL
