Chevrolet Traverse I (2008-2012) 19 14 low ref evap a/c on ind wiring diagram
This page shows the only wiring diagram for the component.19 14 low ref evap a/c on ind, which is found in the car Chevrolet Traverse I (2008-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
19 14 low ref evap a/c on ind wiring diagram (1 of 1)
19 14 LOW REF EVAP A/C ON IND
44 55 42 11 35 39 A/C CLUTCH HI SPD BUS - HI SPD BUS + LOW REF
5 9 12 SERIAL AMBIENT LOW REF
5060 735 61 COMPUTER DATA LINES SYSTEM 20 25
A/C COMPRESSOR CLUTCH (LOWER LEFT FRONT OF ENGINE)
A/C COMPRESSOR CLUTCH RELAY
A/C ON SW
A/C PRESSURE
A/C REFRIGERANT PRESSURE SENSOR (NEAR REAR OF A/C COMPRESSOR)
AC CLTCH FUSE
BLK WIRE
BLK/WHT WIRE
COMPUTER DATA LINES SYSTEM
DK GRN WIRE
DK GRN/WHT WIRE
DRIVER INFORMATION CENTER (DIC) DISPLAY
EMISSION 2 FUSE
ENGINE CONTROL MODULE (ECM) (LEFT SIDE OF ENGINE)
EVAPORATOR TEMPERATURE SENSOR (RIGHT SIDE OF HVAC MODULE)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ POWERTRAIN RELAY ENERGIZED
HVAC CONTROL MODULE
LOGIC
LOGIC INSTRUMENT PANEL CLUSTER (IPC)
LT GRN/BLK WIRE
ORG/BLK WIRE
TAN WIRE
TAN/BLK WIRE
UNDERHOOD FUSE BLOCK (ABOVE RIGHT FRONT WHEELWELL)
WHT WIRE
YEL WIRE
Go to component -> Compressor circuit, manual a/c -> 19 14 LOW REF EVAP A/C ON IND
