Chevrolet TrailBlazer III (2019-2024) fr sunshade sw low ref sroof sw ser data 1 sig Wiring diagram
This page shows the only wiring diagram for the component.fr sunshade sw low ref sroof sw ser data 1 sig, which is found in the car Chevrolet TrailBlazer III (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fr sunshade sw low ref sroof sw ser data 1 sig (1 of 1)
BATTERY POSITIVE VOLT
BATTERY POSITIVE VOLT SUNSHADE MOTOR DOWN CTRL GND
BLK WIRE
BLK/BLU WIRE
BLU WIRE
BLU/GRY WIRE
BODY CRTL MOD LIN BUS 1
CLOSE
COMPUTER DATA LINES SYSTEM
EXPRESS CLOSE
EXPRESS OPEN
FR SUNSHADE SW LOW REF SROOF SW SER DATA 1 SIG
FRONT SUNSHADE SW SIG
GRN/BRN WIRE
HOT AT ALL TIMES
ILL
INSTRUMENT PANEL FUSE BLOCK
LOGIC
ORG/ WIRE
RED/BLU WIRE
SROOF OBST SENSOR SIG 1 SROOF OBST SENSOR SIG 2
SROOF SW LOW REF
SUNROOF SUNSHADE MOTOR
SUNROOF SUNSHADE MOTOR MODULE
SUNROOF SUNSHADE SWITCH
SUNROOF SW LOW REF
SUNROOF SWITCH
SUNSHADE MOTOR UP CTRL
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Power top/sunroof circuit -> FR SUNSHADE SW LOW REF SROOF SW SER DATA 1 SIG
