Car Wiring Diagrams for Electronic power steering circuit for Chevrolet TrailBlazer II facelift (2017-2024)

BATT POSITIVE VOLT BATTERY FUSE BLOCK BLK WIRE BLU WIRE BLU/YEL WIRE COMPUTER DATA LINES SYSTEM DRIVER INFORMATION CENTER DISPLAY GROUND GRY/GRN WIRE HI SPD GMLAN SERIAL DATA (-) (1) HI SPD GMLAN SERIAL DATA (-) (2) HOT AT ALL TIMES INSTRUMENT CLUSTER LOGIC LOW SPD GMLAN SERIAL DATA 2 POWER STEERING CONTROL MODULE (MOUNTED TO STEERING ACTUATOR) RED/GRN WIRE SERIAL DATA COMM ENABLE WHT WIRE WHT/BLU WIRE
