Chevrolet TrailBlazer II facelift (2017-2024) retained accessory power relay coil control Wiring diagrams
This page contains all the electrical diagrams for the component. retained accessory power relay coil control, in which he is found in the car Chevrolet TrailBlazer II facelift (2017-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram retained accessory power relay coil control (1 of 2)
BATT POS VOLT
BLK WIRE
BLK/BRN WIRE
BLU WIRE
BODY CONTROL MODULE (UNDER FRONT OF CENTER CONSOLE)
BRN WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
DRIVER INFORMATION CENTER DISPLAY
GRN/BLU WIRE
GRN/GRY WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GROUND
GRY/BRN WIRE
GRY/GRN WIRE
GRY/VIO WIRE
HIGH SPEED GMLAN SERIAL DATA (-) (1)
HOT AT ALL TIMES
INSTRUMENT CLUSTER
INSTRUMENT PANEL FUSE BLOCK
LOGIC
PARK LOCK SOL CTRL
POWER DISTRIBUTION SYSTEM
PRESS BRAKE IND
RED/BLU WIRE
RED/VIO WIRE
RETAINED ACCESSORY POWER RELAY COIL CONTROL
SERIAL DATA 2
TAP UP/TAP DOWN SW SIG
TRANSMISSION MANUAL SHIFT SWITCH
TRANSMISSION SHIFT LEVER
TRANSMISSION SHIFT LEVER POSITION INDICATOR
TRANSMISSION SHIFT LOCK CONTROL SOLENOID ACTUATOR
VIO WIRE
VIO/BLK WIRE
VIO/WHT WIRE
VIO/YEL WIRE
WHT WIRE
YEL/BLU WIRE
YEL/BRN WIRE
Go to component -> A/t circuit, 2 speed (3 of 4) -> RETAINED ACCESSORY POWER RELAY COIL CONTROL
Wiring diagram retained accessory power relay coil control (2 of 2)
BATT POS VOLT
BLK WIRE
BLK/BRN WIRE
BLU WIRE
BODY CONTROL MODULE
BRN WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
DRIVER INFORMATION CENTER DISPLAY
GRN/BLU WIRE
GRN/GRY WIRE
GRN/YEL WIRE
GROUND
GRY WIRE
GRY/BLK WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/GRN WIRE
GRY/VIO WIRE
HIGH SPEED GMLAN SERIAL DATA (-) (1)
HOT AT ALL TIMES
INSTRUMENT CLUSTER
INSTRUMENT PANEL FUSE BLOCK
LOGIC
PARK LOCK SOL CTRL
POWER DISTRIBUTION SYSTEM
PRESS BRAKE IND
RED/BLU WIRE
RED/VIO WIRE
RETAINED ACCESSORY POWER RELAY COIL CONTROL
SERIAL DATA 2
TAP UP/TAP DOWN SW SIG
TRANSMISSION MANUAL SHIFT SWITCH
TRANSMISSION SHIFT LEVER
TRANSMISSION SHIFT LEVER POSITION INDICATOR
TRANSMISSION SHIFT LOCK CONTROL SOLENOID ACTUATOR
VIO WIRE
VIO/BLK WIRE
VIO/YEL WIRE
WHT WIRE
WHT/BLU WIRE
YEL/BLU WIRE
YEL/BRN WIRE
Go to component -> A/t circuit, 9 speed (2 of 3) -> RETAINED ACCESSORY POWER RELAY COIL CONTROL
