Chevrolet TrailBlazer II facelift (2017-2024) rear axle temp sens Wiring diagram

AWD IND AWD INDICATOR CTRL BATT POS VOLT BLK WIRE BLK/GRY WIRE BLK/VIO WIRE BLU WIRE BLU/ORG WIRE BLU/WHT WIRE BLU/YEL WIRE BODY CONTROL MODULE BRN/GRN WIRE CENTER CONSOLE MULTI-FUNCTION SWITCH COMPUTER DATA LINES SYSTEM DRIVER INFORMATION CENTER DISPLAY GMLAN SERIAL DATA (+) 1 BATT POS VOLT GMLAN SERIAL DATA - 1 GMLAN SERIAL DATA 2 GRN/BRN WIRE GRN/GRY WIRE GROUND GRY/GRN WIRE GRY/YEL WIRE HALL 1 HALL 2 HALL GROUND HALL VCC HOT AT ALL TIMES IND DIMMING CTRL INSTRUMENT CLUSTER LIN BUS 4 LOGIC MOTOR POS SENS LO REF POS SENSOR SIGNAL POWER TRANSFER UNIT SHIFT ACTUATOR PWR TRANSFER MTR CTRL A PWR TRANSFER MTR CTRL B REAR AXLE TEMP SENS REAR AXLE TEMP SENS VOLT REF REAR BODY FUSE BLOCK REAR DIFFERENTIAL CLUTCH CONTROL MODULE REAR DIFFERENTIAL OIL TEMPERATURE SENSOR REAR DIFFERENTIAL CLUTCH SOLENOID VALVE RED/BRN WIRE RED/GRN WIRE RED/VIO WIRE RED/WHT WIRE SENS VOLT REF SERIAL DATA 2 SERIAL DATA COM ENABLE UNDERHOOD FUSE BLOCK VIO WIRE VIO/BRN WIRE VIO/WHT WIRE WHT WIRE WHT/BLU WIRE WHT/RED WIRE
