Chevrolet TrailBlazer II facelift (2017-2024) noise cancellation microphone 4 sig Wiring diagrams
This page contains all the electrical diagrams for the component. noise cancellation microphone 4 sig, in which he is found in the car Chevrolet TrailBlazer II facelift (2017-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram noise cancellation microphone 4 sig (1 of 2)
AUDIO AMPLIFIER (RIGHT REAR WHEEL WELL)
BATT POSITIVE VOLT
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/GRY WIRE
BLU/YEL WIRE
BRN/BLK WIRE
BRN/BLU WIRE
COMPUTER DATA LINES SYSTEM
ETHERNET BUS 6 (-)
GRN WIRE
GRN/BLK WIRE
GRN/BRN WIRE
GRN/VIO WIRE
GROUND
GRY/BLK WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/GRN WIRE
LEFT FRONT ACTIVE NOISE CANCELLATION MICROPHONE
LEFT FRONT SPEAKER CONTROL (+) 1
LEFT REAR ACTIVE NOISE CANCELLATION MICROPHONE
LEFT REAR SPEAKER CONTROL (+)
LEFT/REAR SUBWOOFER CONTROL (-)
LOW SPEED GMLAN SERIAL DATA 2
NOISE CANCELLATION MICROPHONE 1 FEEDBACK SIG
NOISE CANCELLATION MICROPHONE 1 SIG
NOISE CANCELLATION MICROPHONE 2 FEEDBACK SIG
NOISE CANCELLATION MICROPHONE 2 SIG
NOISE CANCELLATION MICROPHONE 3 FEEDBACK SIG
NOISE CANCELLATION MICROPHONE 3 SIG
NOISE CANCELLATION MICROPHONE 4 FEEDBACK SIG
NOISE CANCELLATION MICROPHONE 4 SIG
RED/BRN WIRE
RIGHT FRONT ACTIVE NOISE CANCELLATION MICROPHONE
RIGHT FRONT SPEAKER CONTROL (+) 1
RIGHT REAR ACTIVE NOISE CANCELLATION MICROPHONE
RIGHT REAR SPEAKER CONTROL (+)
RIGHT SUBWOOFER CONTROL (-)
VIO/BLU WIRE
WHT WIRE
WHT/GRN WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Navigation circuit, mid/high level w/ amplifier (4 of 4) -> NOISE CANCELLATION MICROPHONE 4 SIG
Wiring diagram noise cancellation microphone 4 sig (2 of 2)
AUDIO AMPLIFIER (RIGHT REAR WHEEL WELL)
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/GRY WIRE
BLU/YEL WIRE
BRN/BLK WIRE
BRN/BLU WIRE
COMPUTER DATA LINES SYSTEM
ETHERNET BUS 6 (-)
GRN WIRE
GRN/BLK WIRE
GRN/BRN WIRE
GRN/VIO WIRE
GRY/BLK WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/GRN WIRE
LEFT FRONT ACTIVE NOISE CANCELLATION MICROPHONE
LEFT FRONT SPEAKER CONTROL (+) 1 BATT POSITIVE VOLT
LEFT FRONT SPEAKER CONTROL (-) 1 GROUND
LEFT REAR ACTIVE NOISE CANCELLATION MICROPHONE
LEFT REAR SPEAKER CONTROL (+)
LEFT/REAR SUBWOOFER CONTROL (-)
LOW SPEED GMLAN SERIAL DATA 2
NOISE CANCELLATION MICROPHONE 1 FEEDBACK SIG
NOISE CANCELLATION MICROPHONE 1 SIG
NOISE CANCELLATION MICROPHONE 2 FEEDBACK SIG
NOISE CANCELLATION MICROPHONE 2 SIG
NOISE CANCELLATION MICROPHONE 3 FEEDBACK SIG
NOISE CANCELLATION MICROPHONE 3 SIG
NOISE CANCELLATION MICROPHONE 4 FEEDBACK SIG
NOISE CANCELLATION MICROPHONE 4 SIG
RED/BRN WIRE
RIGHT FRONT ACTIVE NOISE CANCELLATION MICROPHONE
RIGHT FRONT SPEAKER CONTROL (+) 1
RIGHT REAR ACTIVE NOISE CANCELLATION MICROPHONE
RIGHT REAR SPEAKER CONTROL (+)
RIGHT SUBWOOFER CONTROL (-)
VIO/BLU WIRE
WHT WIRE
WHT/GRN WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Radio circuit, mid/high level w/ amplifier (4 of 4) -> NOISE CANCELLATION MICROPHONE 4 SIG
