Chevrolet TrailBlazer II facelift (2017-2024) cruise ctrl set/coast/ resume/acc sw sig 12 volt ref Wiring diagram

ACC PEDAL POS 5 VOLT REF (1) ACC PEDAL POS 5 VOLT REF 2 ACC PEDAL POS LOW REF 1 ACC PEDAL POS POS SIG 1 ACC PEDAL POS LOW REF 2 ACC PEDAL POS SIG 2 ACCELERATOR PEDAL POSITION SENSOR BATT POS VOLT BLK WIRE BLK/BLU WIRE BLK/BRN WIRE BLK/GRN WIRE BLK/VIO WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BLU/WHT WIRE BLU/YEL WIRE BODY CONTROL MODULE (UNDER FRONT OF CENTER CONSOLE) BRAKE PEDAL POSITION SENSOR (TOP OF BRAKE PEDAL ASSEMBLY) BRK APPLY SENS CTRL BRK APPLY SENS LOW REF BRK APPLY SENS SIG BRK POS SENS SIG BRN/GRN WIRE BRN/RED WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM CRUISE CTRL SET/COAST/ RESUME/ACC SW SIG 12 VOLT REF CRUISE/ETC/ TCC BRK SIG CRUISE/ETC/TCC BRK SIG DISTANCE SENSING CRUISE CTRL GAP UP/DOWN SW SIG ENGINE CONTROL MODULE ENGINE CTRL SENS LOW REF 2 ENGINE CTRL VEHICLE SENS 5 VOLT REF 1 GRN/ORG WIRE GRN/WHT WIRE GROUND GRY/GRN WIRE HI SPD GMLAN SER DATA (+) 1 HI SPD GMLAN SER DATA (+) 3 HOT AT ALL TIMES HOT W/ IGNITION MAIN RELAY ENERGIZED INSTRUMENT PANEL FUSE BLOCK LEFT STEERING WHEEL CONTROLS SWITCH LOGIC RED/VIO WIRE RUN/CRANK IGNITION 1 VOLT 1 STEERING WHEEL AIR BAG COIL THROTTLE ACTUATOR CLOSE CTRL THROTTLE ACTUATOR OPEN CTRL THROTTLE BODY (MOUNTED TO FRONT OF INTAKE MANIFOLD) THROTTLE POS SENS SENT 1 SIG THROTTLE POS SENS LOW REF UNDERHOOD FUSE BLOCK VIO WIRE VIO/GRN WIRE VIO/GRY WIRE WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/WHT WIRE
