Chevrolet TrailBlazer II facelift (2017-2024) cellular phone, navigation antenna Wiring diagrams

This page contains all the electrical diagrams for the component. cellular phone, navigation antenna, in which he is found in the car Chevrolet TrailBlazer II facelift (2017-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram cellular phone, navigation antenna for Chevrolet TrailBlazer II facelift (2017-2024) (1 of 2)

Get access

AUDIO (-) CONTROL AUDIO SIGNAL BATT POS VOLT BLK WIRE BLK/BLU WIRE BLK/BRN WIRE BLK/GRY WIRE BLU WIRE BLU/BLK WIRE BLU/GRN WIRE BLU/RED WIRE BLUETOOTH BLUETOOTH WIRELESS COMMUNICATION ANTENNA BODY CONTROL MODULE (UNDER FRONT OF CENTER CONSOLE) BRN/BLU WIRE BRN/VIO WIRE CELL CELL/GPS CELLULAR PHONE, NAVIGATION ANTENNA CELLULAR TELEPHONE CLUSTER COAX COMPUTER DATA LINES SYSTEM DOWN DR-D DRIVER INFORMATION CENTER DISPLAY GRN WIRE GRN/BLK WIRE GRN/YEL WIRE GROUND GRY/GRN WIRE GRY/YEL WIRE HIGH SPD GMLAN HIGH SPEED GMLAN SERIAL DATA (-) (1) INSTRUMENT INSTRUMENT CLUSTER LED BACKLIGHT DIMMING CONTROL 1 LEFT FRONT MOBILE TELEPHONE MICROPHONE LIN BUS 1 LOGIC LOW SPD GMLAN MICROPHONE (-) LOW REF MICROPHONE SIGNAL MUTE NCA WIRE ORG/WHT WIRE RED WIRE RED/BLU WIRE RED/BRN WIRE RED/VIO WIRE RED/WHT WIRE RIGHT STEERING WHEEL CONTROLS SWITCH SEEK SEEK UP SERIAL DATA (-) 9 SERIAL DATA 2 SERIAL DATA COMMUNICATION ENABLE SOURCE STEERING WHEEL AIR BAG COIL STEERING WHEEL CONTROLS SIG 1 TELEMATICS COMMUNICATION INTERFACE CONTROL MODULE VOICE VOICE RECOGNITION VOL (-) W/ AUTO HIGH BEAM HEADLAMP CONTROL W/O AUTO HIGH BEAM HEADLAMP CONTROL WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/ORG WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE

Go to component -> Navigation circuit, mid/high level w/ amplifier (2 of 4) -> CELLULAR PHONE, NAVIGATION ANTENNA
