Front wiper/washer circuit for Chevrolet TrailBlazer I facelift (2005-2009)

Front wiper/washer circuit

Get access

ACCESSORY VOLTAGE BLK WIRE BODY CONTROL MODULE (BCM) (BENEATH LEFT REAR SEAT, ON REAR FUSE BLOCK) DK BLU WIRE DK GRN WIRE FRT WPR FUSE 33 GROUND LSD GRY WIRE HEADLIGHTS SYSTEM HI LO OFF HOT AT ALL TIMES HOT IN RUN OR ACC LOGIC WINDSHIELD WIPER SWITCH SIGNAL 2 MIST NOT USED OFF PULSE ORG/ WIRE OUTSIDE MOISTURE SENSOR SIGNAL 1 PNK WIRE RAIN FUSE 29 REAR FUSE BLOCK (BELOW LEFT REAR SEAT) RED WIRE TAN WIRE TURN SIGNAL/ MULTI-FUNCTION SWITCH UNDERHOOD FUSE BLOCK (ON LEFT SIDE OF ENGINE COMPARTMENT) WASH WHT WIRE WINDSHIELD WASHER FLUID PUMP (ON WASHER FLUID RESERVOIR) WINDSHIELD WASHER RELAY CONTROL WINDSHIELD WIPER HIGH SIGNAL WINDSHIELD WIPER MOTOR (ON UPPER CENTER OF FIREWALL) WINDSHIELD WIPER SUPPLY VOLTAGE WINDSHIELD WIPER SWITCH SIGNAL WINDSHIELD WIPER/ WASHER SWITCH WSW FUSE 9 WSW RELAY 42 YEL WIRE
