Chevrolet TrailBlazer I facelift (2005-2009) Adjustable pedal circuit

5 6 7 9 BAT (+) MEMORY 1 SW MEMORY 2 SW ILLUM CTRL ADJ PEDAL RWD SIG ADJ PEDAL FWD SIG ADJ PEDAL SENSOR SIG LUM HORIZ POS SEN SIG AFT BACK UP FUSE 27 BLK WIRE BRN WIRE BRN/WHT WIRE CLASS 2 SERIAL DATA COMPUTER DATA LINES SYSTEM DK BLU WIRE DK GRN WIRE DRIVER DOOR MODULE (DDM) (BELOW DRIVER'S DOOR SWITCH PANEL) DRIVER MEMORY SEAT MODULE (BELOW LEFT FRONT SEAT) DRIVER MEMORY SEAT SWITCH DRIVER SEAT LUMBAR HORIZONTAL POSITION SENSOR EAP FUSE 15 (4.2L) EAP RELAY 49 ELECTRONIC ADJUSTABLE PEDALS (EAP) RELAY (LEFT SIDE OF DASH, ON PEDAL ASSEMBLY) ELECTRONIC ADJUSTABLE PEDALS (EAP) SWITCH ELECTRONIC ADJUSTABLE PEDALS ASSEMBLY FORE/ FUSE 59 (5.3L, 6.0L) FUSE HOLDER HOT AT ALL TIMES HOT IN RUN OR START LOW REF LT GRN WIRE MEM 1 MEM 2 EXIT NCA WIRE ORG/ WIRE PARK/ NEUTRAL PARK/NEUTRAL POSITION (PNP) SWITCH (ON LOWER LEFT SIDE OF TRANSMISSION) PNK WIRE PPL RED WIRE SPLICE PACK TAN WIRE UNDERHOOD FUSE BLOCK (ABOVE LEFT FRONT WHEELWELL) WHT WIRE YEL WIRE
