Chevrolet TrailBlazer I facelift (2005-2009) windshield washer relay control Wiring diagram
This page shows the only wiring diagram for the component.windshield washer relay control, which is found in the car Chevrolet TrailBlazer I facelift (2005-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram windshield washer relay control (1 of 1)
ACCESSORY VOLTAGE
BLK WIRE
BODY CONTROL MODULE (BCM) (BENEATH LEFT REAR SEAT, ON REAR FUSE BLOCK)
DK BLU WIRE
DK GRN WIRE
FRT WPR FUSE 33
GROUND LSD
GRY WIRE
HEADLIGHTS SYSTEM
HI LO OFF
HOT AT ALL TIMES
HOT IN RUN OR ACC
LOGIC WINDSHIELD WIPER SWITCH SIGNAL 2
MIST
NOT USED
OFF PULSE
ORG/ WIRE
OUTSIDE MOISTURE SENSOR SIGNAL 1
PNK WIRE
RAIN FUSE 29
REAR FUSE BLOCK (BELOW LEFT REAR SEAT)
RED WIRE
TAN WIRE
TURN SIGNAL/ MULTI-FUNCTION SWITCH
UNDERHOOD FUSE BLOCK (ON LEFT SIDE OF ENGINE COMPARTMENT)
WASH
WHT WIRE
WINDSHIELD WASHER FLUID PUMP (ON WASHER FLUID RESERVOIR)
WINDSHIELD WASHER RELAY CONTROL
WINDSHIELD WIPER HIGH SIGNAL
WINDSHIELD WIPER MOTOR (ON UPPER CENTER OF FIREWALL)
WINDSHIELD WIPER SUPPLY VOLTAGE
WINDSHIELD WIPER SWITCH SIGNAL
WINDSHIELD WIPER/ WASHER SWITCH
WSW FUSE 9
WSW RELAY 42
YEL WIRE
Go to component -> Front wiper/washer circuit -> WINDSHIELD WASHER RELAY CONTROL
