Chevrolet TrailBlazer I facelift (2005-2009) serial data trac cntrl sw sig tcc brake sw sig Wiring diagram
This page shows the only wiring diagram for the component.serial data trac cntrl sw sig tcc brake sw sig, which is found in the car Chevrolet TrailBlazer I facelift (2005-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram serial data trac cntrl sw sig tcc brake sw sig (1 of 1)
4.2L 5.3L, 6.0L
ABS FUSE 33
ABS PUMP
BATT POS VOLT
BLK WIRE
BRAKE FLUID LEVEL SWITCH (ON BRAKE MASTER CYLINDER FLUID RESERVOIR)
BRAKE FUSE 51
BRN WIRE
CRUISE CONTROL SYSTEM PPL PPL
DK BLU WIRE
DK GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN RUN
HOT IN RUN OR START
HVAC 1 FUSE 39
IGN 3 VOLT
IGN E FUSE 22
LATERAL ACCEL SIG
LEFT FRONT WHEEL SPEED SENSOR (ON LEFT FRONT WHEEL HUB ASSEMBLY)
LEFT REAR WHEEL SPEED SENSOR (ATTACHED TO LEFT REAR WHEEL HUB)
LR WH SPD LOW REF LR WH SPD SIG RR WH SPD SIG RR WH SPD LOW REF
LT BLU WIRE
LT GRN WIRE
NCA WIRE
ORG/BLK WIRE
PNK WIRE
PPL
REAR FUSE BLOCK (BELOW LEFT REAR SEAT)
RED WIRE
RIGHT FRONT WHEEL SPEED SENSOR (ON RIGHT FRONT WHEEL HUB ASSEMBLY)
RIGHT REAR WHEEL SPEED SENSOR (ATTACHED TO RIGHT REAR WHEEL HUB)
SERIAL DATA TRAC CNTRL SW SIG TCC BRAKE SW SIG
STOP LAMP SWITCH (ON BRAKE PEDAL ASSEMBLY)
TAN WIRE
TAN/BLK WIRE
UNDERHOOD FUSE BLOCK (ABOVE LEFT FRONT WHEELWELL)
VSES FUSE 58 FUSE 61
WHT WIRE
YAW RATE SENS SIG YAW RING CNTRL STEER WH POS SIG A
YEL WIRE
Go to component -> Anti-lock brakes circuit (1 of 2) -> SERIAL DATA TRAC CNTRL SW SIG TCC BRAKE SW SIG
