Chevrolet TrailBlazer I facelift (2005-2009) secondary air injection pump relay ignition coil 6 Wiring diagram
This page shows the only wiring diagram for the component.secondary air injection pump relay ignition coil 6, which is found in the car Chevrolet TrailBlazer I facelift (2005-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram secondary air injection pump relay ignition coil 6 (1 of 1)
1-2 SHIFT SOLENOID (1-2 SS) VALVE
4.2L
4.2L 5.3L, 6.0L
AIR SOL FUSE 54
AIR SOL RELAY 55
AUTOMATIC TRANSMISSION
BACKUP FUSE 27
BODY CONTROL MODULE (BCM)
EAP RELAY 49
ECM 1 FUSE 28
ECM FUSE 29
ENGINE CONTROL MODULE (ECM)
ENGINE CONTROL MODULE (PCM) PARK/ NEUTRAL POSITION (PNP) SWITCH
F/PMP RELAY 41
FAN FUSE 20
FAN RELAY 45
FROM AIR SOL FUSE 54
FROM HAZRD FUSE 52 (DIAGRAM 2 OF 6)
FROM IGNITION SWITCH (DIAGRAM 1 OF 6)
FUEL INJECTOR 1 FUEL INJECTOR 2 POWERTRAIN CONTROL MODULE (PCM)
FUEL INJECTOR 3
FUEL INJECTOR 4 FUEL INJECTOR 5
FUEL INJECTOR 6
HDM FUSE 53 FUSE 57
HEADLAMP DRIVER MODULE (HDM) RELAY 46
HI HEADLAMP RELAY 43
IGN COILS FUSE 14
IGNITION COIL 1 IGNITION COIL 2 IGNITION COIL 3
IGNITION COIL 5 IGNITION COIL 4
INPUT SPEED SENSOR (ISS) TORQUE CONVERTER CLUTCH (TCC) SOLENOID VALVE
MODULATION (TCC PWM) SOLENOID
ORG/ WIRE
PCM B FUSE 10
PCM I FUSE 28
PNK PNK (IN FUEL INJECTOR HARNESS) WIRE
PNK PNK PNK WIRE
PNK PNK WIRE
PNK WIRE
POWERTRAIN CONTROL MODULE (PCM)
RED WIRE
SECONDARY AIR INJECTION PUMP RELAY IGNITION COIL 6
TBC 1 FUSE 31 FUSE 58
TO AIRBAG FUSE 18 (DIAGRAM 3 OF 6)
TO IGN E FUSE 22 (DIAGRAM 4 OF 6)
TO POWERTRAIN RELAY 60 (DIAGRAM 6 OF 6)
TORQUE CONVERTER CLUTCH PULSE WIDTH
TRANS FUSE 53
UNDER- HOOD FUSE BLOCK (ABOVE LEFT FRONT WHEELWELL)
VALVE
YEL WIRE
Go to component -> Power distribution circuit (3 of 6) -> SECONDARY AIR INJECTION PUMP RELAY IGNITION COIL 6
