Chevrolet TrailBlazer I facelift (2005-2009) req torq sig pc sol low ctrl Wiring diagram

1-2 SHIFT SOL DELIVERED TORQ SIG 2-3 SHIFT SOL LOW OIL PRESS SW EVAP CAN PRG CTL 10 11 12 13 14 15 16 PNK PNK PNK WIRE ANTI-LOCK BRAKES SYSTEM BLK WIRE BLK/WHT WIRE BRN WIRE DK BLU WIRE DK GRN WIRE DK GRN/WHT WIRE ENGINE OIL PRESSURE SWITCH LOWER RIGHT OF ENGINE BLOCK) GRY WIRE HEATED OXYGEN SENSOR 1 (ON EXHAUST MANIFOLD, ON RIGHT SIDE OF ENGINE) HEATED OXYGEN SENSOR 2 (DOWNSTREAM OF CATALYTIC CONVERTER) LOW REF LT BLU/WHT WIRE LT GRN WIRE LT GRN/BLK WIRE NCA WIRE OIL PRESS SW SIG ORG/BLK WIRE PC SOL HI CTRL TFT SENS SIG PNK WIRE POWERTRAIN CONTROL MODULE (PCM) (UPPER LEFT SIDE OF ENGINE) PPL PPL/WHT WIRE RED WIRE RED/BLK WIRE REQ TORQ SIG PC SOL LOW CTRL TAN WIRE TAN/BLK WIRE TAN/WHT WIRE TCC PWM SOL TCC SOL VLV CTRL TFP SW SIG B VSS LOW SIG VSS HI SIG TFP SW SIG C AIR INJ CTRL VLV 1 TRAN RG SW SIG A 3-2 SHIFT SOL TRS SIG B TRS SIG P UNDERHOOD FUSE BLOCK UNDERHOOD FUSE BLOCK (ON LEFT SIDE OF ENGINE COMPT) WHT WIRE YEL WIRE YEL/BLK WIRE
