Chevrolet TrailBlazer I facelift (2005-2009) regulated voltage control module Wiring diagrams
This page contains all the electrical diagrams for the component. regulated voltage control module, in which he is found in the car Chevrolet TrailBlazer I facelift (2005-2009). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
regulated voltage control module wiring diagram (1 of 2)
4.2L
5.3L, 6.0L 4.2L
A/C COMPRESSOR CLUTCH ASSEMBLY
BARE
BLK WIRE
BRAKE FLUID LEVEL SWITCH
DK GRN WIRE
EAP RELAY 49
ELECTRONIC BRAKE CONTROL MODULE (EBCM)
ENGINE CONTROL MODULE (ECM)
F/PUMP RELAY 41
FAN RELAY 45 HDM RELAY 46
FRONT AXLE ACTUATOR
FRONT PASSENGER DOOR MODULE (FPDM) VEHICLE COMMUNICATION INTERFACE MODULE (VCIM)
GMC, BUICK
HIGH BEAM LOW BEAM
HOOD AJAR SWITCH
LEFT CORNERING LAMP
LEFT FRONT FOG LAMP
LEFT FRONT MARKER LAMP
LEFT FRONT PARK LAMP
LEFT FRONT PARK/TURN SIGNAL LAMP
LEFT FRONT TURN SIGNAL LAMP
LEFT HEADLAMP
MASS AIRFLOW/ INTAKE AIR TEMPERATURE SENSOR
ONSTAR MICROPHONE GROUND SHIELD 2
PARK/ NEUTRAL POSITION (PNP) SWITCH
PASSENGER LUMBAR ADJUSTER SWITCH
PASSENGER SEAT ADJUSTER SWITCH
POWERTRAIN CONTROL MODULE (PCM)
REGULATED VOLTAGE CONTROL MODULE
RIGHT REAR DOOR LATCH ASSEMBLY
RIGHT REAR WINDOW SWITCH
SECONDARY AIR INJECTION (AIR) SOLENOID
TRANSMISSION CONTROL MODULE (TCM)
UNDERHOOD FUSE BLOCK (ABOVE LEFT FRONT WHEELWELL)
W/ 2 SPEED PUSH BUTTON CONTROL
W/ DELUXE SEATS
W/ FRONT FOG LAMPS
W/ GPS 1
W/ WIRING PROVISIONS
WHT WIRE
Go to component -> Ground distribution circuit (2 of 4) -> REGULATED VOLTAGE CONTROL MODULE
regulated voltage control module wiring diagram (2 of 2)
7 CM FROM BREAKOUT, BODY CONNECTOR)
BODY CONTROL MODULE (BCM)
BRN WIRE
DRIVER LUMBAR ADJUSTER SWITCH DRIVER SEAT ADJUSTER SWITCH
DRIVER MEMORY SEAT MODULE
EXCEPT CHEVROLET
F PARK FUSE 37
FLAT WIRE
FLAT WIRE FLAT WIRE
FROM AMP FUSE 11 (DIAGRAM 4 OF 6)
FROM PARK LP RELAY 30 (DIAGRAM 5 OF 6)
FROM TBC 5 FUSE 32
LEFT FRONT PARK/TURN SIGNAL LAMP
LEFT LICENSE LAMP
LEFT TAILLAMP CIRCUIT BOARD
LIFTGATE MODULE (LGM)
LOCK RELAY 18
LOCKS FUSE 21
LR PARK FUSE 14
ORG/ WIRE
PARK LP RELAY 30
PASSENGER LUMBAR ADJUSTER SWITCH PASSENGER SEAT ADJUSTER SWITCH
REAR FUSE BLOCK (BELOW LEFT REAR SEAT)
REAR WINDOW WIPER MOTOR
RED WIRE
REGULATED VOLTAGE CONTROL MODULE
RIGHT FRONT MARKER LAMP
RIGHT FRONT PARK LAMPS LEFT FRONT MARKER LAMP LEFT FRONT PARK LAMPS
RIGHT FRONT PARK/TURN SIGNAL LAMP
RIGHT LICENSE LAMP
RIGHT TAILLAMP CIRCUIT BOARD
RR FOG FUSE 5
RR FOG LP RELAY 45
RR HVAC FUSE 13
RR PARK FUSE 17
RR WIPER CIRCUIT BREAKER 9 LGM 2 FUSE 3
RVC FUSE 49 FUSE 62 (4.2L) (5.3L, 6.0L)
SUNROOF FUSE 28
SUNROOF MOTOR
TBC 3 FUSE 4 TBC 2 FUSE 7
TBC 5 FUSE 32 TBC 4 FUSE 40 (DIAGRAM 5 OF 6)
TO LGM 2 FUSE 3 (DIAGRAM 5 OF 6)
TO SEATS CIRCUT BREAKER 8
TR PARK FUSE 42
TRAILER CONNECTOR
TURN SIGNAL/ MULTIFUNCTION SWITCH
UNDERHOOD FUSE BLOCK (ABOVE LEFT FRONT WHEELWELL)
UNLOCK RELAY 24
W/ DELUXE SEATS
W/ MEMORY
W/ REAR FOG LAMPS
W/O MEMORY
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (5 of 6) -> REGULATED VOLTAGE CONTROL MODULE
