Chevrolet TrailBlazer I facelift (2005-2009) press sw sig b low ref trans range sw b Wiring diagrams
This page contains all the electrical diagrams for the component. press sw sig b low ref trans range sw b, in which he is found in the car Chevrolet TrailBlazer I facelift (2005-2009). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram press sw sig b low ref trans range sw b (1 of 2)
2-3 SS VALV CTRL
3-2 SS VALV CTRL
ACCESSORY VOLT
BLK WIRE
BLK/WHT WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
FRONT HI SIG SERIAL DATA (-) SERIAL DATA (+)
GRY WIRE
HOT AT ALL TIMES
HOT IN ACC OR RUN
HOT IN RUN OR START
IGN E FUSE 22
LT BLU WIRE
LT BLU/WHT WIRE
LT GRN WIRE
LT GRN/BLK WIRE
ORG/ WIRE
PARK/NEUTRAL POSITION (PNP) SWITCH (ON LOWER LEFT SIDE OF TRANSMISSION)
PNK 12 13 WIRE
PNK WIRE
PPL/WHT WIRE
PRESS SW SIG B LOW REF TRANS RANGE SW B
REAR TCM FUSE 35 FUSE BLOCK (BELOW LEFT REAR SEAT)
RED WIRE
RED/BLK WIRE
ST/LP FUSE 12
STOP LAMP SWITCH (ON BRAKE PEDAL ASSEMBLY)
TAN WIRE
TAN/BLK WIRE
TAN/WHT WIRE
TCM/ CANISTER FUSE 15
TFT SENS SIG
TRANS FUSE 53
TRANS RANGE SW A LOW REF IGN 1 VOLT BATT VOLT PRESS SW SIG C
TRANS RANGE SW C PRESS SW SIG A TCC SOL VALV CTRL PNK WIRE
TRANSMISSION CONTROL MODULE (TCM) (LEFT FRONT OF ENGINE)
UNDERHOOD FUSE BLOCK (ABOVE LEFT FRONT WHEELWELL)
VEH STOP FUSE 34
VEHICLE SPEED SENSOR (VSS)
VSS HIGH SIG PC SOL VALV LO CTRL
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> 5.3l vin m, a/t circuit (1 of 2) -> PRESS SW SIG B LOW REF TRANS RANGE SW B
Wiring diagram press sw sig b low ref trans range sw b (2 of 2)
2-3 SS VALV CTRL
3-2 SS VALV CTRL
ACCESSORY VOLT
BLK WIRE
BLK/WHT WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
FRONT HI SIG SERIAL DATA (-) SERIAL DATA (+)
GRY WIRE
HOT AT ALL TIMES
HOT IN ACC OR RUN
HOT IN RUN OR START
IGN E FUSE 22
LT BLU WIRE
LT BLU/WHT WIRE
LT GRN WIRE
LT GRN/BLK WIRE
ORG/ WIRE
PARK/NEUTRAL POSITION (PNP) SWITCH (ON LOWER LEFT SIDE OF TRANSMISSION)
PNK 12 13 WIRE
PNK WIRE
PPL/WHT WIRE
PRESS SW SIG B LOW REF TRANS RANGE SW B
REAR TCM FUSE 35 FUSE BLOCK (BELOW LEFT REAR SEAT)
RED WIRE
RED/BLK WIRE
ST/LP FUSE 12
STOP LAMP SWITCH (ON BRAKE PEDAL ASSEMBLY)
TAN WIRE
TAN/BLK WIRE
TAN/WHT WIRE
TCM/ CANISTER FUSE 15
TFT SENS SIG
TRANS FUSE 53
TRANS RANGE SW A LOW REF IGN 1 VOLT BATT VOLT PRESS SW SIG C
TRANS RANGE SW C PRESS SW SIG A TCC SOL VALV CTRL PNK WIRE
TRANSMISSION CONTROL MODULE (TCM) (LEFT FRONT OF ENGINE)
UNDERHOOD FUSE BLOCK (ABOVE LEFT FRONT WHEELWELL)
VEH STOP FUSE 34
VEHICLE SPEED SENSOR (VSS)
VSS HIGH SIG PC SOL VALV LO CTRL
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> 6.0l vin h, a/t circuit (1 of 2) -> PRESS SW SIG B LOW REF TRANS RANGE SW B
