Chevrolet TrailBlazer I facelift (2005-2009) hdlp wpr relay 37 Wiring diagram
This page shows the only wiring diagram for the component.hdlp wpr relay 37, which is found in the car Chevrolet TrailBlazer I facelift (2005-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hdlp wpr relay 37 (1 of 1)
02 SNSR A FUSE 55
02 SNSR B FUSE 54
02 SNSR FUSE 29
4.2L
4.2L 5.3L, 6.0L
A/C FUSE 30
A/C RELAY 44
BANK 1 SENSOR 1
BANK 1 SENSOR 2 BANK 2 SENSOR 1
BANK 2 SENSOR 2
EAP FUSE 15 FUSE 59
EAP RELAY 49
ELECTRONIC ADJUSTABLE PEDALS RELAY
ENG 1 FUSE 26
ENGINE CONTROL MODULE
ETC FUSE 23
EVAPORATIVE EMISSION (EVAP) CANISTER PURGE SOLENOID
FOG LP FUSE 11
FOG LP RELAY 39
FROM TBC 1 FUSE 31 (DIAGRAM 3 OF 6)
FUEL INJECTOR 1 FUEL INJECTOR 3
FUEL INJECTOR 2
FUEL INJECTOR 5 FUEL INJECTOR 7
FUEL INJECTOR 8 FUEL INJECTOR 6 FUEL INJECTOR 4
HDLP WPR RELAY 37
HEATED OXYGEN SENSOR
HEATED OXYGEN SENSOR HEATED OXYGEN SENSOR
HORN FUSE 21
HORN RELAY 40
IGNITION COIL 2 IGNITION COIL 4
IGNITION COIL 3 IGNITION COIL 1
IGNITION COIL 5 IGNITION COIL 7
IGNITION COIL 8 IGNITION COIL 6
INJA FUSE 31
INJB FUSE 56
MASS AIR FLOW (MAF)/ INTAKE AIR TEMPERATURE (IAT) SENSOR
NCA WIRE
ORG/ WIRE
PNK PNK PNK WIRE
PNK PNK WIRE
PNK WIRE
POWERTRAIN RELAY 57
REAR WPR RELAY 38
RELAY 60
SENSOR 1 SENSOR 2
VALVE LIFTER OIL MANIFOLD (VLOM) ASSEMBLY
W/S WASH RELAY 42
WASH FUSE 9
WPR FUSE 7
Go to component -> Power distribution circuit (6 of 6) -> HDLP WPR RELAY 37
