Chevrolet TrailBlazer I facelift (2005-2009) ground gen reg cntrl class 2 data ppl Wiring diagram
This page shows the only wiring diagram for the component.ground gen reg cntrl class 2 data ppl, which is found in the car Chevrolet TrailBlazer I facelift (2005-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ground gen reg cntrl class 2 data ppl (1 of 1)
4.2L 5.3L, 6.0L
AIR CONDITIONING SYSTEM
BATT + VOLT GEN FIELD DUTY CYC BATT + VOLT GEN TURN ON
BATTERY
BATTERY VOLTAGE
BLK WIRE
BLK/WHT WIRE
CHARGE INDICATOR
CLASS 2
CLASS 2 DATA
DK GRN WIRE
ENGINE CONTROL MODULE (ECM) (5.6L, 6.0L) (NEAR LOWER LEFT FRONT OF ENGINE)
FUSIBLE LINK 1 (8 GA-
GEN FIELD DUTY CYCLE
GENERATOR
GENERATOR REGULATOR CONTROL
GROUND
GROUND GEN REG CNTRL CLASS 2 DATA PPL
GRY WIRE
HOT AT ALL TIMES
INSTRUMENT PANEL CLUSTER (IPC)
IPC/DIC FUSE 24
ORG/ WIRE
POWERTRAIN CONTROL MODULE (PCM) (4.2L) (ON UPPER LEFT SIDE OF ENGINE)
PPL
RED WIRE
REGULATED VOLTAGE CONTROL MODULE (BEHIND BATTERY)
RVC FUSE 59 FUSE 62
STARTER
UNDERHOOD FUSE BLOCK (ABOVE LEFT FRONT WHEELWELL)
VOLTS
WHT WIRE
Go to component -> Charging circuit -> GROUND GEN REG CNTRL CLASS 2 DATA PPL
