Chevrolet TrailBlazer I facelift (2005-2009) driver back heated seat element wiring diagram
This page shows the only wiring diagram for the component.driver back heated seat element, which is found in the car Chevrolet TrailBlazer I facelift (2005-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
driver back heated seat element wiring diagram (1 of 1)
BACK ONLY IND
BACK ONLY INDICATOR
BACK ONLY SELECT
BATT +
BATT + VOLTAGE
BLK WIRE
BRN WIRE
BRN/WHT WIRE
CLASS 2 SERIAL DATA
COMPUTER DATA LINES SYSTEM
DDM FUSE 10
DRIVER BACK HEATED SEAT ELEMENT
DRIVER CUSHION HEATED SEAT ELEMENT
DRIVER DOOR MODULE (DDM) (BELOW DRIVER'S DOOR SWITCH PANEL)
DRIVER MEMORY SEAT MODULE (BELOW LEFT FRONT SEAT)
GND BAT (+)
GRN WIRE
GROUND
HEAT MODE SELECT
HEATED SEAT PWR HEATED SEAT PWR LOW REF HEATED SEAT THERM SIG
HI HEAT IND
HI HEAT INDICATOR
HOT AT ALL TIMES
LGM/DSM FUSE 6
LOW HEAT IND
LOW HEAT INDICATOR
LOW REF
LT DOORS CB 2
LT GRN WIRE
MED HEAT IND
MED HEAT INDICATOR
NCA WIRE
ORG/ WIRE
REAR FUSE BLOCK (BELOW LEFT REAR SEAT)
RED WIRE
SEATS CIRCUIT BREAKER 8
SERIAL DATA
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Driver heated seat circuit -> DRIVER BACK HEATED SEAT ELEMENT
