Chevrolet TrailBlazer I facelift (2005-2009) battery serial data sensor sig Wiring diagram
This page shows the only wiring diagram for the component.battery serial data sensor sig, which is found in the car Chevrolet TrailBlazer I facelift (2005-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram battery serial data sensor sig (1 of 1)
BATTERY SERIAL DATA SENSOR SIG
BLK WIRE
BODY CONTROL MODULE (BCM) (BENEATH LEFT REAR SEAT, ON REAR FUSE BLOCK)
CLASS 2 SERIAL DATA
DATA
DATA LINK CONNECTOR (ON BOTTOM LEFT SIDE OF DASH) PPL
DK GRN WIRE
FLAT WIRE FLAT WIRE
FLAT WIRE FLAT WIRE GROUND GROUND
GRY WIRE
HOT AT ALL TIMES
INSTRUMENT PANEL CLUSTER
LT GRN WIRE
ORG/ WIRE
PASSLOCK
PPL
REAR FUSE BLOCK (BELOW LEFT REAR SEAT)
RED WIRE
RED/WHT WIRE
RTN DATA SENSOR REF (IN IGNITION LOCK CYLINDER CASE)
SECURITY IND
SENSOR RET
SPLICE PACK
TBC 1 FUSE 31 (4.2L) FUSE 58 (5.3L, 6.0L)
UNDERHOOD FUSE BLOCK (ABOVE LEFT FRONT WHEELWELL)
WHT WIRE
YEL WIRE
Go to component -> Passlock circuit -> BATTERY SERIAL DATA SENSOR SIG
