Chevrolet TrailBlazer I facelift (2005-2009) back up lamp supply voltage on/off Wiring diagram
This page shows the only wiring diagram for the component.back up lamp supply voltage on/off, which is found in the car Chevrolet TrailBlazer I facelift (2005-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram back up lamp supply voltage on/off (1 of 1)
BACK UP LAMP SUPPLY VOLTAGE
BACK UP LAMP SUPPLY VOLTAGE ON/OFF
BLK WIRE
BODY CONTROL MODULE (BENEATH LEFT REAR SEAT, ON REAR FUSE BLOCK)
COMPUTER DATA LINES SYSTEM
GROUND
HOT IN RUN OR START
IGN 1
IGN E FUSE 22
INSIDE REARVIEW MIRROR
LOGIC
LT GRN WIRE
NCA WIRE
PHOTO SENSOR
PNK WIRE
REAR FUSE BLOCK (BELOW LEFT REAR SEAT)
SERIAL DATA
UNDERHOOD FUSE BLOCK (ABOVE LEFT FRONT WHEELWELL)
Go to component -> Automatic day/night mirror circuit -> BACK UP LAMP SUPPLY VOLTAGE ON/OFF
