Chevrolet TrailBlazer I facelift (2005-2009) back up fuse 27 Wiring diagram
This page shows the only wiring diagram for the component.back up fuse 27, which is found in the car Chevrolet TrailBlazer I facelift (2005-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram back up fuse 27 (1 of 1)
5 6 7 9 BAT (+) MEMORY 1 SW MEMORY 2 SW ILLUM CTRL
ADJ PEDAL RWD SIG ADJ PEDAL FWD SIG ADJ PEDAL SENSOR SIG LUM HORIZ POS SEN SIG
AFT
BACK UP FUSE 27
BLK WIRE
BRN WIRE
BRN/WHT WIRE
CLASS 2 SERIAL DATA
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK GRN WIRE
DRIVER DOOR MODULE (DDM) (BELOW DRIVER'S DOOR SWITCH PANEL)
DRIVER MEMORY SEAT MODULE (BELOW LEFT FRONT SEAT)
DRIVER MEMORY SEAT SWITCH
DRIVER SEAT LUMBAR HORIZONTAL POSITION SENSOR
EAP FUSE 15 (4.2L)
EAP RELAY 49
ELECTRONIC ADJUSTABLE PEDALS (EAP) RELAY (LEFT SIDE OF DASH, ON PEDAL ASSEMBLY)
ELECTRONIC ADJUSTABLE PEDALS (EAP) SWITCH
ELECTRONIC ADJUSTABLE PEDALS ASSEMBLY
FORE/
FUSE 59 (5.3L, 6.0L)
FUSE HOLDER
HOT AT ALL TIMES
HOT IN RUN OR START
LOW REF
LT GRN WIRE
MEM 1
MEM 2 EXIT
NCA WIRE
ORG/ WIRE
PARK/ NEUTRAL
PARK/NEUTRAL POSITION (PNP) SWITCH (ON LOWER LEFT SIDE OF TRANSMISSION)
PNK WIRE
PPL
RED WIRE
SPLICE PACK
TAN WIRE
UNDERHOOD FUSE BLOCK (ABOVE LEFT FRONT WHEELWELL)
WHT WIRE
YEL WIRE
Go to component -> Adjustable pedal circuit -> BACK UP FUSE 27
