Chevrolet TrailBlazer I facelift (2005-2009) 1 2 3 ground class 2 serial data wiring diagram
This page shows the only wiring diagram for the component.1 2 3 ground class 2 serial data, which is found in the car Chevrolet TrailBlazer I facelift (2005-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
1 2 3 ground class 2 serial data wiring diagram (1 of 1)
1 2 3 GROUND CLASS 2 SERIAL DATA
59 60 L SEAT BELT SW R SEAT BELT SW
7 8 PNK WIRE
BLK WIRE
BLK/WHT WIRE
BRN WIRE
DK BLU WIRE
DK GRN WIRE
DRIVER SEAT BELT BUCKLE
GRN WIRE
GRY WIRE
INFLATABLE RESTRAINT STEERING WHEEL MODULE
INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL (IN STEERING WHEEL COLUMN)
LEFT SEAT BELT PRETENSIONER (UNDER LEFT FRONT OF SEAT, PART OF RETRACTOR)
LT BLU WIRE
LT GRN WIRE
LT GRN/WHT WIRE
NCA WIRE
ORG/ WIRE
ORG/BLK WIRE
PASSENGER SEAT BELT BUCKLE
PIN SHORTING BARS ENGAGED WHEN MODULE CONNECTOR IS DISCONNECTED FROM HARNESS:
PNK SHORTING BAR WIRE
PNK WIRE
PPL
PPL 12 13
RED WIRE
RIGHT SEAT BELT PRETENSIONER (UNDER RIGHT FRONT OF SEAT, PART OF RETRACTOR)
SEAT BELT SWITCH
SHORTING BAR
SHORTING BAR SHORTING BAR
STAGE 1
STAGE 2
STAGE 2 STAGE 1
TAN WIRE
TWISTED PAIR WIRES
TWISTED PAIR WIRES TWISTED PAIR WIRES
WHT WIRE
YEL WIRE
Go to component -> Supplemental restraints circuit (1 of 2) -> 1 2 3 GROUND CLASS 2 SERIAL DATA
