Chevrolet TrailBlazer I (2001-2006) Warning systems circuit

5.3L 4.2L 9 10 11 12 LOW REFERENCE LIFTGLASS AJAR SW LOW REFERENCE LIFTGATE AJAR SW PPL AJAR BELT SW INPUT BLK WIRE BLK/WHT WIRE BODY CONTROL MODULE (BCM) (BENEATH LEFT REAR SEAT, ON REAR FUSE BLOCK) BRN WIRE CLASS 2 SERIAL DATA COMPUTER DATA LINES SYSTEM DK BLU WIRE DK GRN WIRE DOOR DOOR AJAR DR AJAR INPUT DRIVER DOOR LATCH ASSEMBLY DRIVER DOOR MODULE (DDM) (BELOW DRIVER'S DOOR SWITCH PANEL) DRIVER SEAT BELT SWITCH (IN LEFT FRONT SEAT BELT BUCKLE) DRL DEFEAT AUTO DRL DEFEAT AUTO PARK FRONT PASSENGER DOOR MODULE (FPDM) (BELOW FRONT PASSENGER DOOR SWITCH PANEL) GRY WIRE GRY/BLK WIRE HEAD HEADLAMP SWITCH IGNITION KEY ALARM SWITCH INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (SDM) INSTRUMENT PANEL CLUSTER (IPC) KEY IN IGN SW HDLMP ON SIG SW ON INPUT LEFT REAR DOOR LATCH ASSEMBLY LIFTGATE LATCH ASSEMBLY LIFTGATE MODULE (LGM) LIFTGLASS AJAR SWITCH LOGIC LOW REFERENCE LT BLU WIRE LT BLU/BLK WIRE LT GRN WIRE LT GRN/BLK WIRE NCA WIRE ORG/ WIRE PARK HEAD PASSENGER DOOR LATCH ASSEMBLY PNK/BLK WIRE PPL RADIO REAR FUSE BLOCK RIGHT REAR MINIWEDGE (DOOR JAMB SWITCH) RR DR AJAR SIG LR DR AJAR SIG SEAT BELT INDICATOR SERIAL DATA SERIAL DATA (-) SERIAL DATA (+) TAIL GATE AJAR IND TAN WIRE WHT WIRE YEL WIRE
