Chevrolet TrailBlazer I (2001-2006) Ignition lock solenoid circuit

A/T SHIFT LEVER (CLOSED IN PARK) BLK WIRE HOT IN ACC, RUN, START IGN 0 FUSE 47 IGNITION LOCK CYL SWITCH IGNITION LOCK CYLINDER CONTROL ACTUATOR PNK WIRE REAR FUSE BLOCK (BELOW LEFT REAR SEAT) YEL WIRE
