Chevrolet TrailBlazer I (2001-2006) Pass-key circuit

59 58 58 59 DATA DATA BATTERY GROUND SERIAL DATA SENSOR SIG GROUND BLK WIRE BODY CONTROL MODULE (BENEATH LEFT REAR SEAT) COMPUTER DATA LINES DATA LINK CONNECTOR (UNDER LEFT SIDE OF DASH) PPL DK GRN WIRE GRY WIRE HOT AT ALL TIMES INSTRUMENT PANEL CLUSTER LT GRN WIRE NCA WIRE ORG/ WIRE PASSLOCK SENSOR (AT IGNITION SWITCH) PPL REAR FUSE BLOCK (BELOW LEFT REAR SEAT) RED WIRE RED/WHT WIRE RTN DATA REF SECURITY IND SENSOR RET SERIAL DATA SPLICE PACK TBC 1 FUSE 31 UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT) WHT WIRE YEL WIRE
