Chevrolet TrailBlazer I (2001-2006) vss low sig vss high sig Wiring diagram
This page shows the only wiring diagram for the component.vss low sig vss high sig, which is found in the car Chevrolet TrailBlazer I (2001-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram vss low sig vss high sig (1 of 1)
29 30 31 PNK WIRE
3212 23 STARTING/ CHARGING SYSTEM
A/C PRESS SENS GEN ON SIG
A/C SYSTEM
A/C SYSTEM STARTING/CHARGING SYSTEM TRANSMISSION SYSTEM (TRANSFER CASE CIRCUIT)
ANTI-LOCK BRAKES SYSTEM
ANTI-LOCK BRAKES SYSTEM INSTRUMENT CLUSTER SYSTEM
BLK WIRE
BLK/WHT WIRE
BRN WIRE
BRN/WHT WIRE
COOLING FANS SYSTEM
CRANK FUSE
CTRL
DELIVERED TORQ PC SOL HI CTRL
DK BLU WIRE
DK GRN WIRE
DK GRN/WHT WIRE
ENG I FUSE 26
ENGINE SPEED SIGNAL
EVAP PURGE
EVAP VENT CTRL MIL CTRL 2-3 SS CTRL 1-2 SS CTRL VSS OUT VSS OUT TFT SENS SIG
GEN FIELD
GRY WIRE
GRY/BLK WIRE
HOT IN
HOT IN RUN, START
IGN
IGN E FUSE 22
IGNITION COILS
INSTRUMENT PANEL CLUSTER MALFUNCTION INDICATOR LAMP
LOW REF
LT BLU WIRE
LT BLU/WHT WIRE
LT GRN WIRE
LT GRN/BLK WIRE
NCA WIRE
PC SOL LO CTRL PMP RLY CTRL ENGINE SPEED
PCM I FUSE 28
PNK PNK PNK WIRE
PNK WIRE
POWERTRAIN CONTROL MODULE (LOWER LEFT FRONT OF ENGINE)
PPL
PPL FUEL LEV SIG
PPL IGN CTRL 8 IGN CTRL 2 IGN CTRL 5 IGN CTRL 3
PPL PNK PNK WIRE
PPL/WHT WIRE
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
REF LO
SPARK PLUG
SPARK PLUG SPARK PLUG
TAN WIRE
TAN/BLK WIRE
TAN/WHT WIRE
TCC SOL CTRL A/C CLU RLY
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
VSS LOW SIG VSS HIGH SIG
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Wiring diagram engine performance 5.3l vin p (5 of 5) -> VSS LOW SIG VSS HIGH SIG
