Chevrolet TrailBlazer I (2001-2006) rr fog fuse 5 Wiring diagram

AUXILIARY BLOWER MOTOR AUXILIARY BLOWER MOTOR CONTROL PROCESSOR BLK WIRE BLOWER MOTOR AUXILIARY FUSE BODY CONTROL MODULE (BCM) BRN WIRE DK BLU WIRE DK DK DK GRN WIRE DRIVER DOOR MODULE (DDM) F PARK FUSE 37 FLAT WIRE FLAT WIRE FLAT WIRE FROM AMP FUSE 11 (DIAGRAM 4 OF 7) FROM AMP FUSE 11 (DIAGRAM 5 OF 7) FROM TBC 4 FUSE 40 (DIAGRAM 5 OF 7) VENT WDO FUSE 20 FRONT PASSENGER DOOR MODULE (FPDM) FUSE 50 FUSE 51 GMC GRN WIRE INSTRUMENT PANEL CLUSTER (IPC) LEFT CLEARANCE LAMP LEFT FRONT MARKER LAMP LEFT FRONT PARK/TURN SIGNAL LAMP LEFT LICENSE LAMP LEFT QUARTER GLASS SWITCH LEFT TAILLAMP ASSEMBLY LEFT TAILLAMP CIRCUIT BOARD LEFT TAILLAMP CIRCUIT BOARD (CHEVY) LGM 2 FUSE 3 LIFTGATE MODULE (LGM) LR PARK FUSE 14 LT BLU WIRE LT TURN FUSE 38 NCA WIRE ORG/ WIRE OTHERS PARK LP RELAY 50 POWER TOPS SYSTEM REAR FUSE BLOCK REAR WINDOW WIPER MOTOR RED WIRE RETAINED ACCESSORY POWER (RAP) RELAY 22 RIGHT CLEARANCE LAMP RIGHT FRONT MARKER LAMP RIGHT FRONT PARK/TURN SIGNAL LAMP RIGHT LICENSE LAMP RIGHT QUARTER GLASS SWITCH SUNROOF MODULE RIGHT TAILLAMP ASSEMBLY RIGHT TAILLAMP CIRCUIT BOARD RR FOG FUSE 5 RR FOG LP RELAY 45 (EXCEPT XUV) RR PARK FUSE 17 RR WIPER CIRCUIT BREAKER 9 RT TURN FUSE 43 SUNROOF FUSE 20 FUSE 28 RR HVAC FUSE 13 SUNROOF MODULE TAN WIRE TBC 2 FUSE 7 TBC 3 FUSE 4 TBC 5 FUSE 32 TBC 4 FUSE 40 TO RR WIPER CIRCUIT BREAKER 9 (DIAGRAM 5 OF 7) TO VENT WDO FUSE (DIAGRAM 5 OF 7) TR PARK FUSE 42 TRAILER CONNECTOR TRAILER CONNECTORS TRL R TRN TRL L TRN TURN/SIGNAL HAZARD FLASHER MODULE TURN/SIGNAL MULTIFUNCTION SWITCH UNDER- HOOD FUSE BLOCK UNDERHOOD FUSE BLOCK WHT WIRE YEL WIRE
