Chevrolet TrailBlazer I (2001-2006) right license lamp Wiring diagrams
This page contains all the electrical diagrams for the component. right license lamp, in which he is found in the car Chevrolet TrailBlazer I (2001-2006). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram right license lamp (1 of 2)
AUDIO AMPLIFIER
AUXILIARY BLOWER MOTOR CONTROL PROCESSOR (W/ LONG WHEELBASE)
BLK WIRE
CARGO LAMP
CENTER HIGH MOUNTED STOPLAMP (CHMSL)
COIL
ENDGATE LATCH RELAY
ENDGATE MODULE (LGM)
ENDGATE WINDOW REGULATOR
LEFT LICENSE LAMP
LEFT REAR CARGO LAMP
LEFT TAIL LAMP CIRCUIT BOARD
LEFT TAILLAMP CIRCUIT BOARD
LIFTGATE MODULE (LGM)
LONG WHEELBASE
NCA WIRE
REAR AUXILIARY POWER OUTLET
REAR WINDOW DEFOGGER GRID
REAR WINDOW WIPER MOTOR
RIGHT LICENSE LAMP
RIGHT REAR CARGO LAMP
RIGHT TAIL LAMP CIRCUIT BOARD
RIGHT TAILLAMP CIRCUIT BOARD
TRAILER CONNECTOR
W/ PREMIUM PERFORMANCE ENHANCED AUDIO SPEAKER SYSTEM)
W/ SHORT WHEELBASE
WHT WIRE
XUV
Go to component -> Ground distribution circuit (6 of 6) -> RIGHT LICENSE LAMP
Wiring diagram right license lamp (2 of 2)
AUXILIARY BLOWER MOTOR
AUXILIARY BLOWER MOTOR CONTROL PROCESSOR
BLK WIRE
BLOWER MOTOR AUXILIARY FUSE
BODY CONTROL MODULE (BCM)
BRN WIRE
DK BLU WIRE
DK DK
DK GRN WIRE
DRIVER DOOR MODULE (DDM)
F PARK FUSE 37
FLAT WIRE
FLAT WIRE FLAT WIRE
FROM AMP FUSE 11 (DIAGRAM 4 OF 7)
FROM AMP FUSE 11 (DIAGRAM 5 OF 7)
FROM TBC 4 FUSE 40 (DIAGRAM 5 OF 7) VENT WDO FUSE 20
FRONT PASSENGER DOOR MODULE (FPDM)
FUSE 50 FUSE 51
GMC
GRN WIRE
INSTRUMENT PANEL CLUSTER (IPC)
LEFT CLEARANCE LAMP
LEFT FRONT MARKER LAMP
LEFT FRONT PARK/TURN SIGNAL LAMP
LEFT LICENSE LAMP
LEFT QUARTER GLASS SWITCH
LEFT TAILLAMP ASSEMBLY
LEFT TAILLAMP CIRCUIT BOARD
LEFT TAILLAMP CIRCUIT BOARD (CHEVY)
LGM 2 FUSE 3
LIFTGATE MODULE (LGM)
LR PARK FUSE 14
LT BLU WIRE
LT TURN FUSE 38
NCA WIRE
ORG/ WIRE
OTHERS
PARK LP RELAY 50
POWER TOPS SYSTEM
REAR FUSE BLOCK
REAR WINDOW WIPER MOTOR
RED WIRE
RETAINED ACCESSORY POWER (RAP) RELAY 22
RIGHT CLEARANCE LAMP
RIGHT FRONT MARKER LAMP
RIGHT FRONT PARK/TURN SIGNAL LAMP
RIGHT LICENSE LAMP
RIGHT QUARTER GLASS SWITCH SUNROOF MODULE
RIGHT TAILLAMP ASSEMBLY
RIGHT TAILLAMP CIRCUIT BOARD
RR FOG FUSE 5
RR FOG LP RELAY 45 (EXCEPT XUV)
RR PARK FUSE 17
RR WIPER CIRCUIT BREAKER 9
RT TURN FUSE 43
SUNROOF FUSE 20 FUSE 28 RR HVAC FUSE 13
SUNROOF MODULE
TAN WIRE
TBC 2 FUSE 7
TBC 3 FUSE 4
TBC 5 FUSE 32 TBC 4 FUSE 40
TO RR WIPER CIRCUIT BREAKER 9 (DIAGRAM 5 OF 7)
TO VENT WDO FUSE (DIAGRAM 5 OF 7)
TR PARK FUSE 42
TRAILER CONNECTOR
TRAILER CONNECTORS
TRL R TRN TRL L TRN
TURN/SIGNAL HAZARD FLASHER MODULE
TURN/SIGNAL MULTIFUNCTION SWITCH
UNDER- HOOD FUSE BLOCK
UNDERHOOD FUSE BLOCK
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (5 of 7) -> RIGHT LICENSE LAMP
