Chevrolet TrailBlazer I (2001-2006) rf door tweeter speaker Wiring diagrams

ANTENNA BLK/WHT WIRE BODY CONTROL MODULE (BENEATH LEFT REAR SEAT, ON REAR FUSE BLOCK) BRN WIRE DK BLU WIRE DK GRN WIRE GRY WIRE HOT AT ALL TIMES INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL LF DOOR SPEAKER LF DOOR TWEETER SPEAKER LF OUT LR DOOR SPEAKER LR OUT LT BLU WIRE LT GRN WIRE NCA WIRE ORG/ WIRE PNK WIRE RADIO RADIO CONTROL SIGNAL RADIO FUSE 41 REAR FUSE BLOCK (BELOW LEFT REAR SEAT) RF DOOR SPEAKER RF DOOR TWEETER SPEAKER RF OUT RR DOOR SPEAKER RR OUT RR OUT + GROUND SEEK DOWN SEEK PROG SEEK UP SEEK VOICE SERIAL DATA SOURCE DOWN SOURCE UP STEERING WHEEL) SUPPLY VOLTAGE TAN WIRE UPPER LEFT STEERING WHEEL CONTROL SWITCH ASSEMBLY UPPER RIGHT STEERING WHEEL CONTROL SWITCH ASSEMBLY VOLUME DOWN VOLUME UP WHT WIRE WIPER/ WASHER SYSTEM YEL WIRE

BODY CONTROL MODULE (BENEATH LEFT REAR SEAT, ON REAR FUSE BLOCK) BRN WIRE DK BLU WIRE DK GRN WIRE GRY WIRE INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL LF DOOR SPEAKER LF DOOR TWEETER SPEAKER LR DOOR SPEAKER LT BLU WIRE LT GRN WIRE NCA WIRE PNK WIRE RADIO CONTROL SIGNAL RF DOOR SPEAKER RF DOOR TWEETER SPEAKER RR DOOR SPEAKER SEEK DOWN SEEK PROG SEEK UP SEEK VOICE SERIAL DATA SOURCE DOWN SOURCE UP STEERING WHEEL) SUPPLY VOLTAGE TAN WIRE UPPER LEFT STEERING WHEEL CONTROL SWITCH ASSEMBLY UPPER RIGHT STEERING WHEEL CONTROL SWITCH ASSEMBLY VOLUME DOWN VOLUME UP WHT WIRE WIPER/ WASHER SYSTEM YEL WIRE
