Chevrolet TrailBlazer I (2001-2006) outside moisture sensor signal 1 Wiring diagram

1 2 3 ACC VOLTAGE GROUND SENSOR SIGNAL 1 ACCESSORY VOLTAGE BLK WIRE BODY CONTROL MODULE (BENEATH LEFT REAR SEAT, ON FUSE BLOCK) DK BLU WIRE DK GRN WIRE FRT WPR FUSE 33 GROUND LSD GRY WIRE HEADLIGHTS SYSTEM HI LO OFF HOT AT ALL TIMES HOT IN RUN AND ACC LO PULSE MIST MIST WASH OFF ORG/ WIRE OUTSIDE MOISTURE SENSOR OUTSIDE MOISTURE SENSOR SIGNAL 1 PNK WIRE RAIN FUSE 29 REAR FUSE BLOCK (BELOW LEFT REAR SEAT) RED WIRE TAN WIRE TURN SIGNAL/ MULTI-FUNCTION SWITCH UNDERHOOD FUSE BLOCK (ON LEFT SIDE OF ENGINE COMPT) W/S WASH FUSE 9 W/S WASH RELAY 42 WHT WIRE WINDSHIELD WASHER FLUID PUMP (ON WASHER FLUID RESERVOIR) WINDSHIELD WASHER RELAY CNTRL WINDSHIELD WIPER HIGH SIGNAL WINDSHIELD WIPER MOTOR (ON UPPER CENTER OF FIREWALL) WINDSHIELD WIPER SUPPLY VOLTAGE WINDSHIELD WIPER SWITCH SIGNAL WINDSHIELD WIPER SWITCH SIGNAL 2 WINDSHIELD WIPER/ WASHER SWITCH YEL WIRE
