Chevrolet TrailBlazer I (2001-2006) lf sens low ref rf sens sig tcc brake sw Wiring diagram
This page shows the only wiring diagram for the component.lf sens low ref rf sens sig tcc brake sw, which is found in the car Chevrolet TrailBlazer I (2001-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lf sens low ref rf sens sig tcc brake sw (1 of 1)
5.3L 4.2L
ABS FUSE 33
ANTI-LOCK INDICATOR
BLK WIRE
BODY CONTROL MODULE (BCM) (BENEATH LEFT REAR SEAT, ON REAR FUSE BLCK)
BRAKE FLUID LEVEL SWITCH (ON BRAKE MASTER CYLINDER FLUID RESERVOIR)
BRAKE FUSE 51
BRAKE INDICATOR
BRN WIRE
CRUISE CONTROL SYSTEM PPL PPL
DK GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN RUN
HOT IN RUN OR START
IGN 3 ABS PUMP
IGN E FUSE 22
INSTRUMENT PANEL CLUSTER
LEFT FRONT WHEEL SPEED SENSOR
LF SENS LOW REF RF SENS SIG TCC BRAKE SW
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PNK WIRE
PPL
REAR FUSE BLOCK (BELOW LEFT REAR SEAT)
RED WIRE
RIGHT FRONT WHEEL SPEED SENSOR
SERIAL DATA
SERIAL DATA LVL SENS SIG LF SENS SIG RF SEN LOW REF VSS PPL
STOP LAMP SWITCH (ABOVE BRAKE PEDAL, ON BRACKET)
TAN WIRE
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT)
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT) IPC/DIC FUSE 24
VEHICLE SPEED SIGNAL
YEL WIRE
YEL/BLK WIRE
Go to component -> Anti-lock brakes circuit, without traction control -> LF SENS LOW REF RF SENS SIG TCC BRAKE SW
