Chevrolet TrailBlazer I (2001-2006) endgate swing switch Wiring diagram

ANTI-THEFT SYSTEM BATT + BATT + LAMP SUPP LAMP CNTRL BLK WIRE BLU WIRE BODY CONTROL MODULE (BENEATH LEFT REAR SEAT, ON REAR FUSE BLOCK) BRN WIRE CARGO LAMP COURTESY COURTESY LAMP SWITCH DATA DK BLU WIRE DK BLU/WHT WIRE DK DK DK GRN WIRE DOME AJAR DOOR AJAR INPUT DOOR AJAR INPUT (RIGHT FRONT OF LOWER CONSOLE) DRIVER DOOR JAMB SWITCH DRIVER DOOR MODULE (BELOW DOOR SWITCH PANEL) END GATE DOME ENDGATE DROP HANDLE ENDGATE DROP SWITCH ENDGATE MODULE SERIAL DATA CLASS 2 ENDGATE SWING HANDLE ENDGATE SWING SWITCH FRONT PASSENGER DOOR JAMB SWITCH FRONT PASSENGER DOOR MODULE (BELOW DOOR SWITCH PANEL) SERIAL DATA CLASS 2 GRN WIRE GRY WIRE HEADLAMP SWITCH HOT AT ALL TIMES INTERIOR LAMP DEFEAT SWITCH LEFT REAR DOOR JAMB LIFT GATE AJAR INPUT LIFTGATE AJAR SWITCH LIFTGATE LATCH ASSEMBLY LIFTGATE MODULE LONG WHEELBASE LOW REF LOWER LEFT AJAR INPUT UPPER RIGHT AJAR INPUT LOWER LEFT ENDGATE ACTUATOR UPPER RIGHT ENDGATE ACTUATOR LT BLU WIRE LT BLU/BLK WIRE LT GRN WIRE LT GRN/BLK WIRE NCA WIRE ORG/ WIRE PNK WIRE PPL PPL LMP DEFEAT LAMP ON PPL LT READING REAR FUSE BLOCK (BELOW LEFT REAR SEAT) RIGHT REAR DOOR JAMB RR DR SIG LR DR SIG SERIAL DATA CLASS 2 SERIAL DATA CLASS 2 LIFT GLASS AJAR INPUT TAN WIRE TBC 3 FUSE 4 TBC 4 FUSE 40 TO COURTESY/ READING LAMPS (DIAGRAM 2 OF 2) UPPER LEFT AJAR INPUT UPPER LEFT ENDGATE ACTUATOR W/ SPECIAL EDITION WHT WIRE XUV EXCEPT XUV XUV LT XUV, SHORT WHEELBASE YEL WIRE
